Publication 1403-IN054B-EN-P - August 2001
B-20 DeviceNet Data Tables
Instance 16 Attributes (Metering reactive energy results)
Assembly Structure
Common Services
Attribute ID Access
Rule
Name DeviceNet Data Type
3 Get Data Structure of
32 bytes (16 Words)
Param # Parameter name Data type #bytes Master Module Range Word No. Range Modulu
s
1 KVARh forward Modulus 10
0 to 1.0x10
12 1 +0 to 999
10
12
2 +0 to 999
10
9
3 +0 to 999
10
6
4 +0 to 999
10
3
5 +0 to 999
10
0
2 KVARh reverse Modulus 10
–1.0x10
12
to 0
6 –0 to 999
10
12
7 –0 to 999
10
9
8 –0 to 999
10
6
9 –0 to 999
10
3
10 –0 to 999
10
0
3 KVARh net Modulus 10
–1.0x10
12
to 1.0x10
12 11 ±0 to 9999
10
12
12 ±0 to 9999
10
9
13 ±0 to 9999
10
6
14 ±0 to 9999
10
3
15 ±0 to 9999
10
0
4 Metering iteration Int 2 Used by external device to
determine if it has new
metering data. Counts from
0 to 32767, then rolls over
to 0. 16
Service
Code Service Name
0Ehex Get_Attributes_Single
