Rockwell Automation 1403-NDNET DeviceNet Communications Card Installation Instructions - Manual (Page 107)

Publication 1403-IN054B-EN-P - August 2001
DeviceNet Data Tables B-77
610
9
th
harmonic
Float 4 See Instance 43, parameter 5 (harmonic magnitude for I2)
611
10
th
harmonic
Float 4 See Instance 41, parameter 6 (harmonic magnitude for I2)
612
11
th
harmonic
Float 4 See Instance 43, parameter 6 (harmonic magnitude for I2)
613
12
th
harmonic
Float 4 See Instance 41, parameter 7 (harmonic magnitude for I2)
614
13
th
harmonic
Float 4 See Instance 43, parameter 7 (harmonic magnitude for I2)
615
14
th
harmonic
Float 4 See Instance 41, parameter 8 (harmonic magnitude for I2)
616
15
th
harmonic
Float 4 See Instance 43, parameter 8 (harmonic magnitude for I2)
617
16
th
harmonic
Float 4 See Instance 41, parameter 9 (harmonic magnitude for I2)
618
17
th
harmonic
Float 4 See Instance 43, parameter 9 (harmonic magnitude for I2)
619
18 th harmonic
Float 4 See Instance 41, parameter 10 (harmonic magnitude for I2)
620
19
th
harmonic
Float 4 See Instance 43, parameter 10 (harmonic magnitude for I2)
621
20 th harmonic
Float 4 See Instance 41, parameter 11 (harmonic magnitude for I2)
622
21
st
harmonic
Float 4 See Instance 43, parameter 11 (harmonic magnitude for I2)
623
22 nd harmonic
Float 4 See Instance 41, parameter 1 (harmonic magnitude for I2)
624
23
rd
harmonic
Float 4 See Instance 43, parameter 1 (harmonic magnitude for I2)
625
24 th harmonic
Float 4 See Instance 41, parameter 2 (harmonic magnitude for I2)
626
25
th
harmonic
Float 4 See Instance 43, parameter 2 (harmonic magnitude for I2)
627
26 th harmonic
Float 4 See Instance 42, parameter 3 (harmonic magnitude for I2)
628
27 th harmonic
Float 4 See Instance 44, parameter 3 (harmonic magnitude for I2)
629
28 th harmonic
Float 4 See Instance 42, parameter 4 (harmonic magnitude for I2)
630
29 th harmonic
Float 4 See Instance 44, parameter 4 (harmonic magnitude for I2)
631
30 th harmonic
Float 4 See Instance 42, parameter 5 (harmonic magnitude for I2)
632
31 st harmonic
Float 4 See Instance 44, parameter 5 (harmonic magnitude for I2)
633
32 nd harmonic
Float 4 See Instance 42, parameter 6 (harmonic magnitude for I2)
634
33
rd
harmonic
Float 4 See Instance 44, parameter 6 (harmonic magnitude for I2)
635
34 th harmonic
Float 4 See Instance 42, parameter 7 (harmonic magnitude for I2)
636
35
th
harmonic
Float 4 See Instance 44, parameter 7 (harmonic magnitude for I2)
637
36 th harmonic
Float 4 See Instance 42, parameter 8 (harmonic magnitude for I2)
638
37
th
harmonic
Float 4 See Instance 44, parameter 8 (harmonic magnitude for I2)
639
38 th harmonic
Float 4 See Instance 42, parameter 9 (harmonic magnitude for I2)
640
39
th
harmonic
Float 4 See Instance 44, parameter 9 (harmonic magnitude for I2)
641
40 th harmonic
Float 4 See Instance 42, parameter 10 (harmonic magnitude for I2)
642
41
st
harmonic
Float 4 See Instance 44, parameter 10 (harmonic magnitude for I2)
643 Fundamental Float 4 See Instance 43, parameter 1 (phase angle for I2)
644
2
nd
harmonic
Float 4 See Instance 41, parameter 2 (phase angle for I2)
645
3
rd
harmonic
Float 4 See Instance 43, parameter 2 (phase angle for I2)
646
4
th
harmonic
Float 4 See Instance 41, parameter 3 (phase angle for I2)
647
5
th
harmonic
Float 4 See Instance 43, parameter 3 (phase angle for I2)
Param # Parameter name Data type #bytes Comment
