Publication 1403-IN054B-EN-P - August 2001
B-90 DeviceNet Data Tables
Common Services
Class 2 - Message Router
Object Class Code: 0x02
No attributes or services.
Number of Instances: 1
Class 3 - DeviceNet Object Class Code: 0x03
Class Attributes
Number of Instances: 1
Instance Attributes
Common services
Service Code Implemented for: Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x05 No Yes Reset
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name DeviceNet
Data Type Data Value
1 Get Revision UINT 01
Attribute ID Access Rule Name DeviceNet
Data Type Data Value
1 Get Node Address USINT 63
2 Get Data Rate USINT 0
3 Get BOI BOOL 0
4 Get/Set Bus-Off Counter USINT 0 - 255
5 Get Allocation Info:
Allocation Choice Byte
Master’s Node Addr Data
Structure:
BYTE
USINT
0-3
0-63
Service Code Implemented for: Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
0x4B No Yes Allocate_Master/Slave_Connect
ion_Set
0x4C No Yes Allocate_Master/Slave_Connect
ion_Set
