Rockwell Automation 1403-NDNET DeviceNet Communications Card Installation Instructions - Manual (Page 100)

Publication 1403-IN054B-EN-P - August 2001
B-70 DeviceNet Data Tables
342 Fundamental Float 4 See Instance 43, parameter 1 (harmonic magnitude for I1)
343
2
nd
harmonic
Float 4 See Instance 41, parameter 2 (harmonic magnitude for I1)
344
3 rd harmonic
Float 4 See Instance 43, parameter 2 (harmonic magnitude for I1)
345
4
th
harmonic
Float 4 See Instance 41, parameter 3 (harmonic magnitude for I1)
346
5 th harmonic
Float 4 See Instance 43, parameter 3 (harmonic magnitude for I1)
347
6
th
harmonic
Float 4 See Instance 41, parameter 4 (harmonic magnitude for I1)
348
7 th harmonic
Float 4 See Instance 43, parameter 4 (harmonic magnitude for I1)
349
8 th harmonic
Float 4 See Instance 41, parameter 5 (harmonic magnitude for I1)
350
9 th harmonic
Float 4 See Instance 43, parameter 5 (harmonic magnitude for I1)
351
10 th harmonic
Float 4 See Instance 41, parameter 6 (harmonic magnitude for I1)
352
11 th harmonic
Float 4 See Instance 43, parameter 6 (harmonic magnitude for I1)
353
12 th harmonic
Float 4 See Instance 41, parameter 7 (harmonic magnitude for I1)
354
13
th harmonic
Float 4 See Instance 43, parameter 7 (harmonic magnitude for I1)
355
14
th
harmonic
Float 4 See Instance 41, parameter 8 (harmonic magnitude for I1)
356
15
th
harmonic
Float 4 See Instance 43, parameter 8 (harmonic magnitude for I1)
357
16
th
harmonic
Float 4 See Instance 41, parameter 9 (harmonic magnitude for I1)
358
17 th harmonic
Float 4 See Instance 43, parameter 9 (harmonic magnitude for I1)
359
18
th
harmonic
Float 4 See Instance 41, parameter 10 (harmonic magnitude for I1)
360
19 th harmonic
Float 4 See Instance 43, parameter 10 (harmonic magnitude for I1)
361
20
th
harmonic
Float 4 See Instance 41, parameter 11 (harmonic magnitude for I1)
362
21 st harmonic
Float 4 See Instance 43, parameter 11 (harmonic magnitude for I1)
363
22
nd
harmonic
Float 4 See Instance 42, parameter 1 (harmonic magnitude for I1)
364
23
rd
harmonic
Float 4 See Instance 44, parameter 1 (harmonic magnitude for I1)
365
24
th
harmonic
Float 4 See Instance 42, parameter 2 (harmonic magnitude for I1)
366
25
th
harmonic
Float 4 See Instance 44, parameter 2 (harmonic magnitude for I1)
367
26
th
harmonic
Float 4 See Instance 42, parameter 3 (harmonic magnitude for I1)
368
27
th
harmonic
Float 4 See Instance 44, parameter 3 (harmonic magnitude for I1)
369
28
th
harmonic
Float 4 See Instance 42, parameter 4 (harmonic magnitude for I1)
370
29
th
harmonic
Float 4 See Instance 44, parameter 4 (harmonic magnitude for I1)
371
30
th
harmonic
Float 4 See Instance 42, parameter 5 (harmonic magnitude for I1)
372
31
st
harmonic
Float 4 See Instance 44, parameter 5 (harmonic magnitude for I1)
373
32
nd
harmonic
Float 4 See Instance 42, parameter 6 (harmonic magnitude for I1)
374
33
rd
harmonic
Float 4 See Instance 44, parameter 6 (harmonic magnitude for I1)
375
34
th
harmonic
Float 4 See Instance 42, parameter 7 (harmonic magnitude for I1)
376
35
th
harmonic
Float 4 See Instance 44, parameter 7 (harmonic magnitude for I1)
377
36
th
harmonic
Float 4 See Instance 42, parameter 8 (harmonic magnitude for I1)
378
37
th
harmonic
Float 4 See Instance 44, parameter 8 (harmonic magnitude for I1)
379
38
th
harmonic
Float 4 See Instance 42, parameter 9 (harmonic magnitude for I1)
Param # Parameter name Data type #bytes Comment
