Publication 1403-IN054B-EN-P - August 2001
B-36 DeviceNet Data Tables
Available Min/Max Log Paramters
Parameter
Number Parameter Description Parameter
Number Parameter Description
1 Phase 1 current 43 Phase 2 distortion power factor
2 Phase 2 current 44 Phase 3 distortion power factor
3 Phase 3 current 45 Total distortion power factor
4 Phase 4 current 46 Current demand
5 Average current 47 Real power demand
6 Positive sequence current 48 Reactive power demand
7 Negative sequence current 49 Apparent power demand
8 Current unbalance 50 Phase 1 voltage IEEE THD
9 Phase 1 L-L voltage 51 Phase 1 voltage IEC THD
10 Phase 2 L-L voltage 52
Phase 1 voltage TIF
(1)
11 Phase 3 L-L voltage 53 Phase 1 voltage Crest factor
12 Auxiliary voltage 54
Phase 1 voltage K-factor
(1)
13 Average L-L voltage 55 Phase 1 current IEEE THD
14 Positive sequence voltage 56 Phase 1 current IEC THD
15 Negative sequence voltage 57
Phase 1 current TIF (1)
16 Voltage unbalance 58 Phase 1 current Crest factor
17 Phase 1 L-N voltage 59
Phase 1 current K-factor (1)
18 Phase 2 L-N voltage 60 Phase 2 voltage IEEE THD
19 Phase 3 L-N voltage 61 Phase 2 voltage IEC THD
20 Average L-N voltage 62
Phase 2 voltage TIF (1)
21 Frequency 63 Phase 2 voltage Crest factor
22 Phase 1 real power 64
Phase 2 voltage K-factor
(1)
23 Phase 2 real power 65 Phase 2 current IEEE THD
24 Phase 3 real power 66 Phase 2 current IEC THD
25 Total real power 67
Phase 2 current TIF (1)
26 Phase 1 reactive power 68 Phase 2 current Crest factor
27 Phase 2 reactive power 69
Phase 2 current K-factor
(1)
28 Phase 3 reactive power 70 Phase 3 voltage IEEE THD
29 Total reactive power 71 Phase 3 voltage IEC THD
30 Phase 1 apparent power 72
Phase 3 voltage TIF (1)
31 Phase 2 apparent power 73 Phase 3 voltage Crest factor
32 Phase 3 apparent power 74
Phase 3 voltage K-factor
(1)
33 Total apparent power 75 Phase 3 current IEEE THD
34 Phase 1 true power factor 76 Phase 3 current IEC THD
35 Phase 2 true power factor 77
Phase 3 current TIF (1)
36 Phase 3 true power factor 78 Phase 3 current Crest factor
37 Total true power factor 79
Phase 3 current K-factor
(1)
38 Phase 1 displacement power factor 80 Phase 4 current IEEE THD
39 Phase 2 displacement power factor 81 Phase 4 current IEC THD
40 Phase 3 displacement power factor 82
Phase 4 current TIF (1)
41 Total displacement power factor 83 Phase 4 current Crest factor
42 Phase 1 distortion power factor 84
Phase 4 current K-factor (1)
(1) Available on 1403-MM only.
