B-40 DeviceNet Data Tables
Common Services
Instance 35 Attributes (Oscillography configuration/readback
data select)
Assembly Structure
10 Setpoint action Int 2 0 to 20 13
11 Setpoint level (float value) Float 4
±9999.0x10
21
If limit stored in event log is an integer, this
returns to 0.
14
15
Param # Parameter name Data type #bytes Master Module Range Word No.
Service
Code Service Name
0Ehex Get_Attributes_Single
Attribute
ID Access
Rule Name DeviceNet
Data Type
3 Set Data Structure of
18 bytes (9 Words) (when Master
Module firmware is V2.10 or earlier)
22 bytes (11 Words) (when Master
Module firmware is V3.00 or later)
Param # Parameter name Data Type # bytes Description Default
Setting Word No.
1 Password Int 2 The correct password (0 to 9999) is required to
configure/reconfigure oscillograph functionality, but
not required to select oscillograph data to be read
back. If the user is only selecting data to be read, set
password to –1. - 1
2 Initiate a capture Int 2 0 = Do not initiate a capture
1 = Initiate a capture #1
2 = Initiate capture #2
1
- 2
3 Clear hold of
capture Int 2 Effective only when Buffer Type (parameter 6) is
configured in ‘Hold’ mode.
0 = No effect
1 = Clear hold of capture #1
2 = Clear hold of capture #2
1
- 3
4 Channel to read Int 2 Specifies the oscillograph channel to get during a
subsequent read of .
1 = Capture #1 V1 11 = Capture #2 V1
2 = Capture #1 I1 12 = Capture #2 I1
3 = Capture #1 V2 13 = Capture #2 V2
4 = Capture #1 I2 14 = Capture #2 I2
5 = Capture #1 V3 15 = Capture #2 V3
6 = Capture #1 I3 16 = Capture #2 I3
7 = Capture #1 I4 17 = Capture #2 I4
8 = Channel A
9 = Channel B - 4
