Publication 1403-IN054B-EN-P - August 2001
B-76 DeviceNet Data Tables
572
13
th
harmonic
Float
4
See Instance 43, parameter 7 (% harmonic distortion for I2)
573
14
th
harmonic
Float
4
See Instance 41, parameter 8 (% harmonic distortion for I2)
574
15
th
harmonic
Float
4
See Instance 43, parameter 8 (% harmonic distortion for I2)
575
16
th
harmonic
Float
4
See Instance 41, parameter 9 (% harmonic distortion for I2)
576
17
th
harmonic
Float
4
See Instance 43, parameter 9 (% harmonic distortion for I2)
577
18
th
harmonic
Float
4
See Instance 41, parameter 10 (% harmonic distortion for I2)
578
19
th
harmonic
Float
4
See Instance 43, parameter 10 (% harmonic distortion for I2)
579
20
th
harmonic
Float
4
See Instance 41, parameter 11 (% harmonic distortion for I2)
580
21
st
harmonic
Float
4
See Instance 43, parameter 11 (% harmonic distortion for I2)
581
22
nd
harmonic
Float
4
See Instance 42, parameter 1 (% harmonic distortion for I2)
582
23
rd
harmonic
Float
4
See Instance 44, parameter 1 (% harmonic distortion for I2)
583
24
th
harmonic
Float
4
See Instance 42, parameter 2 (% harmonic distortion for I2)
584
25
th
harmonic
Float
4
See Instance 44, parameter 2 (% harmonic distortion for I2)
585
26
th
harmonic
Float
4
See Instance 42, parameter 3 (% harmonic distortion for I2)
586
27
th
harmonic
Float
4
See Instance 44, parameter 3 (% harmonic distortion for I2)
587
28
th
harmonic
Float
4
See Instance 42, parameter 4 (% harmonic distortion for I2)
588
29
th
harmonic
Float
4
See Instance 44, parameter 4 (% harmonic distortion for I2)
589
30
th
harmonic
Float
4
See Instance 42, parameter 5 (% harmonic distortion for I2)
590
31
st
harmonic
Float
4
See Instance 44, parameter 5 (% harmonic distortion for I2)
591
32
nd
harmonic
Float
4
See Instance 42, parameter 6 (% harmonic distortion for I2)
592
33
rd
harmonic
Float
4
See Instance 44, parameter 6 (% harmonic distortion for I2)
593
34
th
harmonic
Float
4
See Instance 42, parameter 7 (% harmonic distortion for I2)
594
35
th
harmonic
Float
4
See Instance 44, parameter 7 (% harmonic distortion for I2)
595
36
th
harmonic
Float
4
See Instance 42, parameter 8 (% harmonic distortion for I2)
596
37
th
harmonic
Float
4
See Instance 44, parameter 8 (% harmonic distortion for I2)
597
38
th
harmonic
Float
4
See Instance 42, parameter 9 (% harmonic distortion for I2)
598
39
th
harmonic
Float
4
See Instance 44, parameter 9 (% harmonic distortion for I2)
599
40
th
harmonic
Float
4
See Instance 42, parameter 10 (% harmonic distortion for I2)
600
41
st
harmonic
Float
4
See Instance 44, parameter 10 (% harmonic distortion for I2)
601
FFT iteration
Int
2
See Instance 44, parameter 13 (% harmonic distortion for I2)
602
Fundamental
Float
4
See Instance 43, parameter 1 (harmonic magnitude for I2)
603
2
nd
harmonic
Float
4
See Instance 41, parameter 2 (harmonic magnitude for I2)
604
3
rd
harmonic
Float
4
See Instance 43, parameter 2 (harmonic magnitude for I2)
605
4
th
harmonic
Float
4
See Instance 41, parameter 3 (harmonic magnitude for I2)
606
5
th
harmonic
Float
4
See Instance 43, parameter 3 (harmonic magnitude for I2)
607
6
th
harmonic
Float
4
See Instance 41, parameter 4 (harmonic magnitude for I2)
608
7
th
harmonic
Float
4
See Instance 43, parameter 4 (harmonic magnitude for I2)
609
8
th
harmonic
Float
4
See Instance 41, parameter 5 (harmonic magnitude for I2)
Param # Parameter name
Data type #bytes
Comment
