Publication 1403-IN054A-EN-P - August 2001
1-8 Product Description
Table 1.4 Communication Configuration Items
Communication Parameter Description
New Node Address Enter the node address (0 to 64) (default is
63) of the Powermonitor II on the DeviceNet
link. A node address change takes effect on
reset.
New Baud Rate The options are 125K, 250K, 500K, AUTO
and PGM (default is 125K). The selected
baud rate takes effect after a reset. The
maximum cable length is restricted at
higher baud rates.
Bus-Off Interrupt Specify what occurs when a CAN bus-off
interrupt occurs in the DeviceNet network.
The Powermonitor II is not allowed network
access when Hold in Reset is selected and
a bus-off interrupt occurs. HOLD IN RESET
stops communication and waits for power
to be cycled.
RESET AND CONTINUE resets DeviceNet
communications and attempts to
re-establish the communication link.
