Rockwell Automation 1403-NDNET DeviceNet Communications Card Installation Instructions - Manual (Page 110)

Publication 1403-IN054B-EN-P - August 2001
B-80 DeviceNet Data Tables
724
35
th
harmonic
Float 4 See Instance 44, parameter 7 (% harmonic distortion for V3)
725
36
th
harmonic
Float 4 See Instance 42, parameter 8 (% harmonic distortion for V3)
726
37
th
harmonic
Float 4 See Instance 44, parameter 8 (% harmonic distortion for V3)
727
38
th
harmonic
Float 4 See Instance 42, parameter 9 (% harmonic distortion for V3)
728
39
th
harmonic
Float 4 See Instance 44, parameter 9 (% harmonic distortion for V3)
729
40
th
harmonic
Float 4 See Instance 42, parameter 10 (% harmonic distortion for V3)
730
41
st
harmonic
Float 4 See Instance 44, parameter 10 (% harmonic distortion for V3)
731 FFT iteration Int 2 See Instance 44, parameter 13 (% harmonic distortion for V3)
732 Fundamental Float 4 See Instance 43, parameter 1 (harmonic magnitude for V3)
733
2 nd harmonic
Float 4 See Instance 41, parameter 2 (harmonic magnitude for V3)
734
3
rd
harmonic
Float 4 See Instance 43, parameter 2 (harmonic magnitude for V3)
735
4
th
harmonic
Float 4 See Instance 41, parameter 3 (harmonic magnitude for V3)
736
5
th
harmonic
Float 4 See Instance 43, parameter 3 (harmonic magnitude for V3)
737
6
th
harmonic
Float 4 See Instance 41, parameter 4 (harmonic magnitude for V3)
738
7
th
harmonic
Float 4 See Instance 43, parameter 4 (harmonic magnitude for V3)
739
8
th
harmonic
Float 4 See Instance 41, parameter 5 (harmonic magnitude for V3)
740
9
th
harmonic
Float 4 See Instance 43, parameter 5 (harmonic magnitude for V3)
741
10
th
harmonic
Float 4 See Instance 41, parameter 6 (harmonic magnitude for V3)
742
11
th
harmonic
Float 4 See Instance 43, parameter 6 (harmonic magnitude for V3)
743
12
th
harmonic
Float 4 See Instance 41, parameter 7 (harmonic magnitude for V3)
744
13
th
harmonic
Float 4 See Instance 43, parameter 7 (harmonic magnitude for V3)
745
14
th
harmonic
Float 4 See Instance 41, parameter 8 (harmonic magnitude for V3)
746
15
th
harmonic
Float 4 See Instance 43, parameter 8 (harmonic magnitude for V3)
747
16
th
harmonic
Float 4 See Instance 41, parameter 9 (harmonic magnitude for V3)
748
17
th
harmonic
Float 4 See Instance 43, parameter 9 (harmonic magnitude for V3)
749
18
th
harmonic
Float 4 See Instance 41, parameter 10 (harmonic magnitude for V3)
750
19
th
harmonic
Float 4 See Instance 43, parameter 10 (harmonic magnitude for V3)
751
20
th
harmonic
Float 4 See Instance 41, parameter 11 (harmonic magnitude for V3)
752
21
st
harmonic
Float 4 See Instance 43, parameter 11 (harmonic magnitude for V3)
753
22
nd
harmonic
Float 4 See Instance 42, parameter 1 (harmonic magnitude for V3)
754
23
rd
harmonic
Float 4 See Instance 44, parameter 1 (harmonic magnitude for V3)
755
24
th
harmonic
Float 4 See Instance 42, parameter 2 (harmonic magnitude for V3)
756
25
th
harmonic
Float 4 See Instance 44, parameter 2 (harmonic magnitude for V3)
757
26
th
harmonic
Float 4 See Instance 42, parameter 3 (harmonic magnitude for V3)
758
27
th
harmonic
Float 4 See Instance 44, parameter 3 (harmonic magnitude for V3)
759
28
th
harmonic
Float 4 See Instance 42, parameter 4 (harmonic magnitude for V3)
760
29
th
harmonic
Float 4 See Instance 44, parameter 4 (harmonic magnitude for V3)
761
30
th
harmonic
Float 4 See Instance 42, parameter 5 (harmonic magnitude for V3)
Param # Parameter name Data type #bytes Comment
