Rockwell Automation 1403-NDNET DeviceNet Communications Card Installation Instructions - Manual (Page 113)

Publication 1403-IN054B-EN-P - August 2001
DeviceNet Data Tables B-83
839
20
th
harmonic
Float 4 See Instance 41, parameter 11 (% harmonic distortion for I3)
840
21
st
harmonic
Float 4 See Instance 43, parameter 11 (% harmonic distortion for I3)
841
22
nd
harmonic
Float 4 See Instance 42, parameter 1 (% harmonic distortion for I3)
842
23
rd
harmonic
Float 4 See Instance 44, parameter 1 (% harmonic distortion for I3)
843
24
th
harmonic
Float 4 See Instance 42, parameter 2 (% harmonic distortion for I3)
844
25
th
harmonic
Float 4 See Instance 44, parameter 2 (% harmonic distortion for I3)
845
26
th
harmonic
Float 4 See Instance 42, parameter 3 (% harmonic distortion for I3)
846
27
th
harmonic
Float 4 See Instance 44, parameter 3 (% harmonic distortion for I3)
847
28
th
harmonic
Float 4 See Instance 42, parameter 4 (% harmonic distortion for I3)
848
29 th harmonic
Float 4 See Instance 44, parameter 4 (% harmonic distortion for I3)
849
30
th
harmonic
Float 4 See Instance 42, parameter 5 (% harmonic distortion for I3)
850
31 st harmonic
Float 4 See Instance 44, parameter 5 (% harmonic distortion for I3)
851
32
nd
harmonic
Float 4 See Instance 42, parameter 6 (% harmonic distortion for I3)
852
33 rd harmonic
Float 4 See Instance 44, parameter 6 (% harmonic distortion for I3)
853
34
th
harmonic
Float 4 See Instance 42, parameter 7 (% harmonic distortion for I3)
854
35 th harmonic
Float 4 See Instance 44, parameter 7 (% harmonic distortion for I3)
855
36
th
harmonic
Float 4 See Instance 42, parameter 8 (% harmonic distortion for I3)
856
37 th harmonic
Float 4 See Instance 44, parameter 8 (% harmonic distortion for I3)
857
38 th harmonic
Float 4 See Instance 42, parameter 9 (% harmonic distortion for I3)
858
39 th harmonic
Float 4 See Instance 44, parameter 9 (% harmonic distortion for I3)
859
40 th harmonic
Float 4 See Instance 42, parameter 10 (% harmonic distortion for I3)
860
41 st harmonic
Float 4 See Instance 44, parameter 10 (% harmonic distortion for I3)
861 FFT iteration Int 2 See Instance 42, parameter 13 (% harmonic distortion for I3)
862 Fundamental Float 4 See Instance 43, parameter 1 (harmonic magnitude for I3)
863
2
nd
harmonic
Float 4 See Instance 41, parameter 2 (harmonic magnitude for I3)
864
3
rd
harmonic
Float 4 See Instance 43, parameter 2 (harmonic magnitude for I3)
865
4
th
harmonic
Float 4 See Instance 41, parameter 3 (harmonic magnitude for I3)
866
5
th
harmonic
Float 4 See Instance 43, parameter 3 (harmonic magnitude for I3)
867
6
th
harmonic
Float 4 See Instance 41, parameter 4 (harmonic magnitude for I3)
868
7
th
harmonic
Float 4 See Instance 43, parameter 4 (harmonic magnitude for I3)
869
8
th
harmonic
Float 4 See Instance 41, parameter 5 (harmonic magnitude for I3)
870
9
th
harmonic
Float 4 See Instance 43, parameter 5 (harmonic magnitude for I3)
871
10
th
harmonic
Float 4 See Instance 41, parameter 6 (harmonic magnitude for I3)
872
11
th
harmonic
Float 4 See Instance 43, parameter 6 (harmonic magnitude for I3)
873
12
th
harmonic
Float 4 See Instance 41, parameter 7 (harmonic magnitude for I3)
874
13
th
harmonic
Float 4 See Instance 43, parameter 7 (harmonic magnitude for I3)
875
14
th
harmonic
Float 4 See Instance 41, parameter 8 (harmonic magnitude for I3)
876
15
th
harmonic
Float 4 See Instance 43, parameter 8 (harmonic magnitude for I3)
Param # Parameter name Data type #bytes Comment
