General operation, Communications card set-up, Indicators – Rockwell Automation 1403-NDNET DeviceNet Communications Card Installation Instructions User Manual
Page 11

Publication 1403-IN054A-EN-P - August 2001
Product Description 1-5
General Operation
Communications Card Set-Up
All DeviceNet card configuration items such as node address, baud
rate, and bus-off interrupt are set by configuring the Master Module.
Indicators
Two LED indicators provide information about the operating status of
the card.
Table 1.2 LED Indicators
Name
LED Color
LED State and Communications Condition
Module Status
Red/Green
OFF = Power off or Powermonitor II not initialized
RED = Communications Card Failure - may need replacing
GREEN = Powered and self test OK
Network Status
Red/Green
OFF = Power off or device not online
RED = Non-recoverable communication error; check wiring and configuration parameters
FLASHING RED = Communications Failure; Communications Card restarting
FLASHING GREEN = Network status OK, no connections established
GREEN = Network status OK, connections established
