B-2 DeviceNet Data Tables
DeviceNet Object Classes
The 1403-NDNET device supports the following DeviceNet object
classes.
Data Table List
Class
Object
0x01
Identify
0x03
DeviceNet
0x04
Assembly
0x05
Connection
Table
Page Number
Instance 1 Attributes (Input Data Assembly)
Instance 2 Attributes (Output Data Assembly)
Instance 3 Attributes (Input Configuration Data Write)
Instance 4 Attributes (Input Configuration Data Read)
Instance 5 Attributes (Basic Device Configuration Data Write)
Instance 6 Attributes (Basic Device Configuration Data Read)
Instance 7 Attributes (Advanced Configuration Data Write)
Instance 8 Attributes (Advanced Configuration Data Read)
Instance 9 Attributes (DeviceNet Communication Configuration Write)
Instance 10 Attributes (DeviceNet Communication Configuration Read)
Instance 11 Attributes (Metering voltage, current, and frequency results)
Instance 12 Attributes (Sequence voltages and currents)
Instance 13 Attributes (Metering power results)
Instance 14 Attributes (Metering power factor results)
Instance 15 Attributes (Metering real energy results)
Instance 16 Attributes (Metering reactive energy results)
Instance 17 Attributes (Metering demand results)
Instance 18 Attributes (Metering perdicted demand results)
Instance 19 Attributes (Master module selftest results)
Instance 20 Attributes (Setpoint setup/readback select)
Instance 21 Attributes (Setpoint configuration read)
Instance 22 Attributes (Setpoint status information)
Instance 23 Attributes (Snapshot configuration/readback record select)
Instance 24 Attributes (Read of snapshot configuration)
Instance 25 Attributes (Voltage & Current Snapshot data)
Instance 26 Attributes (L4, Unbalance & Frequency Snapshot data)
