Powermonitor ii without a scanner, Multiple concurrent clients – Rockwell Automation 1403-NDNET DeviceNet Communications Card Installation Instructions User Manual
Page 27
Publication 1403-IN054A-EN-P - August 2001
Product Description 1-21
Powermonitor II without a Scanner
The Powermonitor II can communicate directly to other DeviceNet
devices, such as the PanelView family of products, without using a
DeviceNet scanner module.
The Powermonitor II accomplishes this by supporting Explicit Server
Messaging, as shown below.
Multiple Concurrent Clients
For Enhanced DeviceNet V2 Powermonitor II’s only: Up to 4
concurrent clients may be serviced by one Powermonitor II with the
Enhanced DeviceNet V2 communication card. Four explicit messaging
server connections will be supported by the Powermonitor II.
Powermonitor II
1403-MM05A
1403-NDNET
PanelView
DeviceNet
