Publication 1403-IN054B-EN-P - August 2001
B-48 DeviceNet Data Tables
Assembly Structure
Common Services
Param # Parameter name Data
type #bytes Master Module Range Word No.
1 Fundamental Float 4
0 to 100%, 0 to 9999x10
21,
or 0 to 360
degrees, depending on most recent write to
Instance 43, parameter 3.
1
2
2
2 nd harmonic
Float 4 3
4
3
4
th
harmonic
Float 4 5
6
4
6
th
harmonic
Float 4 7
8
5
8 th harmonic
Float 4 9
10
6
10
th
harmonic
Float 4 11
12
7
12
th
harmonic
Float 4 13
14
8
14 th harmonic
Float 4 15
16
9
16
th
harmonic
Float 4 17
18
10
18
th
harmonic
Float 4 19
20
11
20 th harmonic
Float 4 21
22
12 Channel # returned Int 2 1 = L1 Voltage
2 = L1 Current
3 = L2 Voltage
4 = L2 Current
5 = L3 Voltage
6 = L3 Current
7 = L4 Current 23
13 Type of harmonic
data returned Int 2 Matches type of data requested in Instance
38, parameter 3. 24
14 FFT iteration Int 2 0 to 32767 25
Service
Code Service Name
0Ehex Get_Attributes_Single
