B-78 DeviceNet Data Tables
648
6
th
harmonic
Float 4 See Instance 41, parameter 4 (phase angle for I2)
649
7
th
harmonic
Float 4 See Instance 43, parameter 4 (phase angle for I2)
650
8
th
harmonic
Float 4 See Instance 41, parameter 5 (phase angle for I2)
651
9
th
harmonic
Float 4 See Instance 43, parameter 5 (phase angle for I2)
652
10
th
harmonic
Float 4 See Instance 41, parameter 6 (phase angle for I2)
653
11
th
harmonic
Float 4 See Instance 43, parameter 6 (phase angle for I2)
654
12
th
harmonic
Float 4 See Instance 41, parameter 7 (phase angle for I2)
655
13
th
harmonic
Float 4 See Instance 43, parameter 7 (phase angle for I2)
656
14
th
harmonic
Float 4 See Instance 41, parameter 8 (phase angle for I2)
657
15 th harmonic
Float 4 See Instance 43, parameter 8 (phase angle for I2)
658
16
th
harmonic
Float 4 See Instance 41, parameter 9 (phase angle for I2)
659
17 th harmonic
Float 4 See Instance 43, parameter 9 (phase angle for I2)
660
18
th
harmonic
Float 4 See Instance 41, parameter 10 (phase angle for I2)
661
19 th harmonic
Float 4 See Instance 43, parameter 10 (phase angle for I2)
662
20
th
harmonic
Float 4 See Instance 41, parameter 11 (phase angle for I2)
663
21 st harmonic
Float 4 See Instance 43, parameter 11 (phase angle for I2)
664
22
nd
harmonic
Float 4 See Instance 42, parameter 1 (phase angle for I2)
665
23 rd harmonic
Float 4 See Instance 44, parameter 1 (phase angle for I2)
666
24 th harmonic
Float 4 See Instance 42, parameter 2 (phase angle for I2)
667
25 th harmonic
Float 4 See Instance 44, parameter 2 (phase angle for I2)
668
26 th harmonic
Float 4 See Instance 42, parameter 3 (phase angle for I2)
669
27 th harmonic
Float 4 See Instance 44, parameter 3 (phase angle for I2)
670
28 th harmonic
Float 4 See Instance 42, parameter 4 (phase angle for I2)
671
29 th harmonic
Float 4 See Instance 44, parameter 4 (phase angle for I2)
672
30
th
harmonic
Float 4 See Instance 42, parameter 5 (phase angle for I2)
673
31 st harmonic
Float 4 See Instance 44, parameter 5 (phase angle for I2)
674
32
nd
harmonic
Float 4 See Instance 42, parameter 6 (phase angle for I2)
675
33 rd harmonic
Float 4 See Instance 44, parameter 6 (phase angle for I2)
676
34
th
harmonic
Float 4 See Instance 42, parameter 7 (phase angle for I2)
677
35 th harmonic
Float 4 See Instance 44, parameter 7 (phase angle for I2)
678
36
th
harmonic
Float 4 See Instance 42, parameter 8 (phase angle for I2)
679
37 th harmonic
Float 4 See Instance 44, parameter 8 (phase angle for I2)
680
38
th
harmonic
Float 4 See Instance 42, parameter 9 (phase angle for I2)
681
39
th
harmonic
Float 4 See Instance 44, parameter 9 (phase angle for I2)
682
40
th
harmonic
Float 4 See Instance 42, parameter 10 (phase angle for I2)
683
41
st
harmonic
Float 4 See Instance 44, parameter 10 (phase angle for I2)
684 IEEE THD Float 4 See Instance 40, parameter 1 (for V3)
685 IEC thd Float 4 See Instance 40, parameter 2 (for V3)
Param # Parameter name Data type #bytes Comment
