Publication 1403-IN054B-EN-P - August 2001
DeviceNet Data Tables B-87
992 Fundamental Float 4 See Instance 43, parameter 1 (harmonic magnitude for I4)
993
2
nd
harmonic
Float 4 See Instance 41, parameter 2 (harmonic magnitude for I4)
994
3 rd harmonic
Float 4 See Instance 43, parameter 2 (harmonic magnitude for I4)
995
4
th
harmonic
Float 4 See Instance 41, parameter 3 (harmonic magnitude for I4)
996
5 th harmonic
Float 4 See Instance 43, parameter 3 (harmonic magnitude for I4)
997
6
th
harmonic
Float 4 See Instance 41, parameter 4 (harmonic magnitude for I4)
998
7 th harmonic
Float 4 See Instance 43, parameter 4 (harmonic magnitude for I4)
999
8 th harmonic
Float 4 See Instance 41, parameter 5 (harmonic magnitude for I4)
1000
9 th harmonic
Float 4 See Instance 43, parameter 5 (harmonic magnitude for I4)
1001
10 th harmonic
Float 4 See Instance 41, parameter 6 (harmonic magnitude for I4)
1002
11 th harmonic
Float 4 See Instance 43, parameter 6 (harmonic magnitude for I4)
1003
12 th harmonic
Float 4 See Instance 41, parameter 7 (harmonic magnitude for I4)
1004
13
th harmonic
Float 4 See Instance 43, parameter 7 (harmonic magnitude for I4)
1005
14
th
harmonic
Float 4 See Instance 41, parameter 8 (harmonic magnitude for I4)
1006
15
th
harmonic
Float 4 See Instance 43, parameter 8 (harmonic magnitude for I4)
1007
16
th
harmonic
Float 4 See Instance 41, parameter 9 (harmonic magnitude for I4)
1008
17 th harmonic
Float 4 See Instance 43, parameter 9 (harmonic magnitude for I4)
1009
18
th
harmonic
Float 4 See Instance 41, parameter 10 (harmonic magnitude for I4)
1010
19 th harmonic
Float 4 See Instance 43, parameter 10 (harmonic magnitude for I4)
1011
20
th
harmonic
Float 4 See Instance 41, parameter 11 (harmonic magnitude for I4)
1012
21 st harmonic
Float 4 See Instance 43, parameter 11 (harmonic magnitude for I4)
1013
22
nd
harmonic
Float 4 See Instance 42, parameter 1 (harmonic magnitude for I4)
1014
23
rd
harmonic
Float 4 See Instance 44, parameter 1 (harmonic magnitude for I4)
1015
24
th
harmonic
Float 4 See Instance 42, parameter 2 (harmonic magnitude for I4)
1016
25
th
harmonic
Float 4 See Instance 44, parameter 2 (harmonic magnitude for I4)
1017
26
th
harmonic
Float 4 See Instance 42, parameter 3 (harmonic magnitude for I4)
1018
27
th
harmonic
Float 4 See Instance 44, parameter 3 (harmonic magnitude for I4)
1019
28
th
harmonic
Float 4 See Instance 42, parameter 4 (harmonic magnitude for I4)
1020
29
th
harmonic
Float 4 See Instance 44, parameter 4 (harmonic magnitude for I4)
1021
30
th
harmonic
Float 4 See Instance 42, parameter 5 (harmonic magnitude for I4)
1022
31
st
harmonic
Float 4 See Instance 44, parameter 5 (harmonic magnitude for I4)
1023
32
nd
harmonic
Float 4 See Instance 42, parameter 6 (harmonic magnitude for I4)
1024
33
rd
harmonic
Float 4 See Instance 44, parameter 6 (harmonic magnitude for I4)
1025
34
th
harmonic
Float 4 See Instance 42, parameter 7 (harmonic magnitude for I4)
1026
35
th
harmonic
Float 4 See Instance 44, parameter 7 (harmonic magnitude for I4)
1027
36
th
harmonic
Float 4 See Instance 42, parameter 8 (harmonic magnitude for I4)
1028
37
th
harmonic
Float 4 See Instance 44, parameter 8 (harmonic magnitude for I4)
1029
38
th
harmonic
Float 4 See Instance 42, parameter 9 (harmonic magnitude for I4)
Param # Parameter name Data type #bytes Comment
