Publication 1403-IN054B-EN-P - August 2001
B-6 DeviceNet Data Tables
Common Services
Instance 4 Attributes (Input Configuration Data Read)
Assembly Structure
13 Selection for parameter #9 Int 2 See “Configurable channel parameter list” on page 61. 13
14 Selection for parameter #10 Int 2 See “Configurable channel parameter list” on page 61. 14
15 Selection for parameter #11 Int 2 See “Configurable channel parameter list” on page 61. 15
16 Selection for parameter #12 Int 2 See “Configurable channel parameter list” on page 61. 16
17 Selection for parameter #13 Int 2 17
18 Selection for parameter #14 Int 2 See “Configurable channel parameter list” on page 61. 18
19 Selection for parameter #15 Int 2 See “Configurable channel parameter list” on page 61. 19
20 Selection for parameter #16 Int 2 See “Configurable channel parameter list” on page 61. 20
21 Selection for parameter #17 Int 2 See “Configurable channel parameter list” on page 61. 21
22 Selection for parameter #18 Int 2 See “Configurable channel parameter list” on page 61. 22
23 Selection for parameter #19 Int 2 See “Configurable channel parameter list” on page 61. 23
24 Selection for parameter #20 Int 2 See “Configurable channel parameter list” on page 61. 24
25 Selection for parameter #21 Int 2 See “Configurable channel parameter list” on page 61. 25
26 Selection for parameter #22 Int 2 See “Configurable channel parameter list” on page 61. 26
Param # Parameter name Data type #bytes Comment Word
No.
Service
Code Service Name
10 hex Set_Attributes_Single
Attribute ID Access
Rule
Name DeviceNet Data Type
3 Get Data Structure of
52 bytes (104 Bits)
Param # Parameter name Data type #bytes Comment Word No.
1 Present unit password Int 2 Current PMII password
1
2 Channel # to configure Int 2 Valid channel numbers are 1 and 49.
2
3 Total parameters in channel Int 2 Total number of parameters in the newly configured
channel.
3
4 Total words in channel Int 2 Total number of words in the newly configured
channel. This should match the total number of words
for all parameters. Max of 64 words 4
5 Selection for parameter #1 Int 2 0-65535 indicates the parameter which the user has
selected to appear in the channel as parameter #1. A
list of parameters can be found in table “Configurable
channel parameter list” on page B-61 5
6 Selection for parameter #2 Int 2 See “Configurable channel parameter list” on page 61. 6
7 Selection for parameter #3 Int 2 See “Configurable channel parameter list” on page 61. 7
