Publication 1403-IN054B-EN-P - August 2001
B-44 DeviceNet Data Tables
Common Services
Instance 38 Attributes (harmonic Analysis
configuration/readback data select)
10
Oscillogram data point 6
Int
2
Data point = (Block# - 1)*18 + 5
13
11
Oscillogram data point 7
Int
2
Data point = (Block# - 1)*18 + 6
14
12
Oscillogram data point 8
Int
2
Data point = (Block# - 1)*18 + 7
15
13
Oscillogram data point 9
Int
2
Data point = (Block# - 1)*18 + 8
16
14
Oscillogram data point 10
Int
2
Data point = (Block# - 1)*18 + 9
17
15
Oscillogram data point 11
Int
2
Data point = (Block# - 1)*18 + 10
18
16
Oscillogram data point 12
Int
2
Data point = (Block# - 1)*18 + 11
19
17
Oscillogram data point 13
Int
2
Data point = (Block# - 1)*18 + 12
20
18
Oscillogram data point 14
Int
2
Data point = (Block# - 1)*18 + 13
21
19
Oscillogram data point 15
Int
2
Data point = (Block# - 1)*18 + 14
22
20
Oscillogram data point 16
Int
2
Data point = (Block# - 1)*18 + 15
23
21
Oscillogram data point 17
Int
2
Data point = (Block# - 1)*18 + 16
24
22
Oscillogram data point 18
Int
2
Data point = (Block# - 1)*18 + 17
25
(1) Available on Master Module firmware V3.00 or later (not implemented on previous versions).
Param
#
Parameter name
Data
Type
# bytes
Description
Word No.
Service
Code
Service Name
0Ehex
Get_Attributes_Single
Attribute
ID
Access
Rule
Name
DeviceNet
Data Type
3
Set
Data
Structure of
16 bytes (8 Words)
