Publication 1403-IN054B-EN-P - August 2001
DeviceNet Data Tables B-29
Assembly Structure
Common Services
Param # Parameter name Data Type # bytes Description Default
Setting Word No.
1 Snapshot interval;
hours Int 2 Indicates the time interval (in hours) between saving of
snapshot records. 1
2 Snapshot interval;
minutes Int 2 Indicates the time interval (in minutes) between saving
of snapshot records. 2
3 Snapshot interval;
seconds Int 2 Indicates the time interval (in seconds) between saving
of snapshot records. 3
4 Snapshot buffer
type Int 2 Indicates how the snapshot log (buffer) is filled.
0= Fill and stop
1= Circular 4
5 #Records in
Snapshot Log Int 2 Indicates how many records are currently stored in the
snapshot log. 5
6 Snapshot log
type
(1)
Int 2 Indicates how many parameters are stored in each
snapshot record.
0= 46 parameter record
1= 16 parameter record
2= 8 parameter record
3= 4 parameter record
4= 3&7 parameter record
5= 1 parameter record 6
7 Snapshot param
#1
(1)
Int 2 Indicates the parameter recorded in a snapshot record
when ‘3&7 parameter’ or ‘1 parameter record’ is
configured as the ‘Snapshot log type’. 7
8 Snapshot param
#2
(1)
Int 2
Indicates the 2
nd
parameter recorded in a snapshot
record when ‘3&7 parameter’ is configured as the
‘Snapshot log type’.
8
9 Snapshot param
#3
(1)
Int 2 Indicates the 3rd parameter recorded in a snapshot
record when ‘3&7 parameter’ is configured as the
‘Snapshot log type’. 9
(1) This parameter is available only with firmware V3.00 or later (not implemented in previous versions).
Service
Code Service Name
0Ehex Get_Attributes_Single
