Publication 1403-IN054B-EN-P - August 2001
DeviceNet Data Tables B-65
149 Snapshot interval; hours Int 2 See Instance 25, parameter 1
150 Snapshot interval; minutes Int 2 See Instance 25, parameter 2
151 Snapshot interval; seconds Int 2 See Instance 25, parameter 3
152 Snapshot buffer type Int 2 See Instance 25, parameter 4
153 # Records in snapshot log Int 2 See Instance 25, parameter 5
154 Enable/disable min/max log Int 2 See Instance 31, parameter 1
155 Timestamp of last min/max clear Int x 4 8 See Instance 31, parameter 2
156 Enable/disable save of status input
changes to event log Int 2 See Instance 34, parameter 1
157 Number of event in the event log Int 2 See Instance 34, parameter 2
158 Oscillograph type Int 2 See Instance 37, parameter 2
159 Ch A 12 cycle oscillogram Int 2 See Instance 37, parameter 3
160 Ch B 12 cycle oscillogram Int 2 See Instance 37, parameter 4
161 Number of pre-trigger cycles Int 2 See Instance 37, parameter 5
162 IEEE 519 max short circuit current Float 4 See Instance 39, parameter 3
163 IEEE 519 max demand/load current Float 4 See Instance 39, parameter 4
164 IEEE THD Float 4 See Instance 40, parameter 1 (for V1)
165 IEC thd Float 4 See Instance 40, parameter 2 (for V1)
166 TIF Float 4 See Instance 40, parameter 3 (for V1)
167 Crest factor Float 4 See Instance 40, parameter 4 (for V1)
168 K-factor Float 4 See Instance 40, parameter 5 (for V1)
169 IEEE 519 pass/fail Int 4 See Instance 40, parameter 6 (for V1)
170 Fundamental Float 4 See Instance 43, parameter 1 (% harmonic distortion for V1)
171
2
nd
harmonic
Float 4 See Instance 41, parameter 2 (% harmonic distortion for V1)
172
3
rd
harmonic
Float 4 See Instance 43, parameter 2 (% harmonic distortion for V1)
173
4
th
harmonic
Float 4 See Instance 41, parameter 3 (% harmonic distortion for V1)
174
5
th
harmonic
Float 4 See Instance 43, parameter 3 (% harmonic distortion for V1)
175
6
th
harmonic
Float 4 See Instance 41, parameter 4 (% harmonic distortion for V1)
176
7
th
harmonic
Float 4 See Instance 43, parameter 4 (% harmonic distortion for V1)
177
8
th
harmonic
Float 4 See Instance 41, parameter 5 (% harmonic distortion for V1)
178
9
th
harmonic
Float 4 See Instance 43, parameter 5 (% harmonic distortion for V1)
179
10
th
harmonic
Float 4 See Instance 41, parameter 6 (% harmonic distortion for V1)
180
11
th
harmonic
Float 4 See Instance 43, parameter 6 (% harmonic distortion for V1)
181
12
th
harmonic
Float 4 See Instance 41, parameter 7 (% harmonic distortion for V1)
182
13
th
harmonic
Float 4 See Instance 43, parameter 7 (% harmonic distortion for V1)
183
14
th
harmonic
Float 4 See Instance 41, parameter 8 (% harmonic distortion for V1)
184
15
th
harmonic
Float 4 See Instance 43, parameter 8 (% harmonic distortion for V1)
185
16
th
harmonic
Float 4 See Instance 41, parameter 9 (% harmonic distortion for V1)
186
17
th
harmonic
Float 4 See Instance 43, parameter 9 (% harmonic distortion for V1)
187
18
th
harmonic
Float 4 See Instance 41, parameter 10 (% harmonic distortion for V1)
188
19
th
harmonic
Float 4 See Instance 43, parameter 10 (% harmonic distortion for V1)
Param # Parameter name Data type #bytes Comment
