B-28 DeviceNet Data Tables
Common Services
Instance 24 Attributes (Read of snapshot configuration)
8 Snapshot log
type
(1)
Int 2 Determines how many parameters are stored in each
snapshot record.
0= 46 parameter record
1= 16 parameter record
2= 8 parameter record
3= 4 parameter record
4= 3&7 parameter record
5= 1 parameter record 0 8
9 Snapshot param
#1
(1)
Int 2 Selects the parameter recorded in a snapshot record
when ‘3&7 parameter’ or ‘1 parameter record’ is
configured as the ‘Snapshot log type’. See “Snapshot
log record parameter list” on page B-30 for a list of
parameters to choose from. 62 9
10 Snapshot param
#2
(1)
Int 2
Selects the 2
nd
parameter recorded in a snapshot
record when ‘3&7 parameter’ is configured as the
‘Snapshot log type’. See “Snapshot log record
parameter list” on page B-30 for a list of parameters to
choose from.
63 10
11 Snapshot param
#3
(1)
Int 2 Selects the 3rd parameter recorded in a snapshot
record when ‘3&7 parameter’ is configured as the
‘Snapshot log type’. See “Snapshot log record
parameter list” on page B-30 for a list of parameters to
choose from. 47 11
(1) This parameter is available only with firmware V3.00 or later (not implemented in previous versions).
Param # Parameter name Data Type # bytes Description Default
Setting Word No.
Service
Code Service Name
10 hex Set_Attributes_Single
Attribute ID Access
Rule
Name DeviceNet Data Type
3 Get Data Structure of
10 bytes (5 Words) (When Master Module firmware
is V2.10 or earlier)
18 bytes (9 Words) (When Master Module firmware
is V3.00 or later)
