Troubleshooting 7-7
23 Net Comm Flt The module detected a communications fault on the network.
24 Net Sent
Reset The module received a reset from the network.
25 Net Close Flt An I/O connection from the network to the module was closed.
26 Net Idle Flt The module is receiving “Idle” packets from the network.
27 Net Open An I/O connection to the module from the network has been
opened.
28 Net Timeout
Flt An I/O connection from the network to the module has timed
out.
29 PCCC IO
Close
The device sending PCCC control messages to the module has
sent the PCCC Control Timeout to a value of zero.
30 PCCC IO
Open
The module has begun receiving PCCC control messages (the
PCCC Control Timeout was previously set to a non-zero value).
31 PCCC IO
Time Flt The module has not received a PCCC control message within
the specified PCCC Control Timeout interval.
32 Watchdog
T/O Flt The software detects a failure.
33 EEPROM Init Startup sequence detected a blank EEPROM map revision.
Intended to happen in factory test.
34 Normal
Startup The module successfully started up.
35 Manual Reset The module was reset by the user.
36 ENET Link
Down The Ethernet link was removed from the module.
37 ENET Link
Up An Ethernet link is available for the module.
38 BOOTP
Response The module received a response to its BOOTP request.
39 Duplicate IP
Addr The module uses the same IP address as another device on the
network.
40 Peer IO Open The module received the first Peer I/O message.
41 Peer IO Time
Flt The module has not received a Peer I/O message for longer
than the Peer I/O Timeout.
42 Email Failure The module attempted to send an e-mail notice, but could not
deliver the message to the mail server.
Code Event Description
