Configuring the Module 3-7
By default, the module is set to autodetect, so it automatically detects the
data rate and duplex setting used on the network. If you need to set a
specific data rate and duplex setting, the value of Parameter 27 - [EN
Rate Cfg] determines the Ethernet data rate and duplex setting that the
module will use to communicate. For definitions of data rate and duplex,
refer to the
Glossary .
1. Set the value of Parameter 27 - [EN Rate Cfg] to the data rate at
which your network is operating.
2. Reset the module. See Resetting the Module section in this chapter.
The I/O configuration determines the data that is sent to and from the
drive. Logic Command/Status, Reference/Feedback, and Datalinks may
be enabled or disabled. A “1” enables the I/O. A “0” disables the I/O.
1. Set the bits in Parameter 32 - [SP I/O Cfg].
Bit 0 is the right-most bit.
2. If Logic Command/Reference is enabled, configure the parameters in
the drive to accept the Logic Command and Reference from the
module. For example, set Parameter 5 - [Freq Select 1] in a 1305
Setting the Data Rate
Table 3.B Parameter 27 - [EN Rate Cfg] Data Rate Setup Values
Value Data Rate
0
Autodetect (default)
1 10 Mbps Full
2 10 Mbps Half
3 100 Mbps Full
4 100 Mbps Half
Setting the I/O Configuration
Table 3.C Parameter 32 - [SP I/O Cfg] Bit Assignments
Bit Description
0 Logic Command/Reference (Default)
1 Datalink A
2 Datalink B
3 Datalink C
4 Datalink D
5 - 7 Not Used
