C-18 EtherNet/IP Objects
Class Code
Instances
The number of instances depends on the number of components in the
device. The total number of components can be read in Instance 0, Class
Attribute 4.
Class Attributes
SCANport Device Object
Hexadecimal Decimal
0x92 146
Instances (Hex.) (Dec.) Device Example Description
0x0000 – 0x3FFF 0 – 16383 Host 0 Class Attributes (Drive)
0x4000 – 0x43FF 16384 – 17407 Module 1 Drive Component 1
2 Drive Component 2
… …
16384 Class Attributes (Module)
16385 Module Component 1
… …
Attribute
ID Access
Rule
Name Data Type Description
0 Get Family Code BYTE 0x00 = Communications Module
0x02 = 1336 PLUS Fractional HP
0x03 = 1336 PLUS
0x07 = 1336 PLUS II
0x10 = 1336 FORCE w/PLC Adapt. Bd.
0x11 = 2364 RGU DC Bus Regen Frt. End
0x12 = 1394 Motion Drive
0x13 = 1557 Medium Voltage AC Drive
0x14 = SMP-3
0x15 = SMC Dialog Plus
0x17 = 1305 AC Drive
0x18 = 1397 DC Drive
0x19 = 1336 Line Regeneration Pkge.
0x20 = 1336 FORCE w/Std. Adapt. Bd.
0x22 = 1336 IMPACT
0x30 = PowerFlex 70
0x38, 0x39, or 0x3A = PowerFlex 700
0x40 = PowerFlex 7000
1 Get Family Text STRING[16] Text identifying the device.
