3-6
Configuring the Module
3. Reset the module. See
The Net A status indicator will be solid green or flashing green if the
IP address is correctly configured.
To set a subnet mask using parameters
1. Verify that Parameter 02 - [BOOTP] is set to Disabled. This
parameter must be set to Disabled to configure the subnet mask using
parameters.
2. Set the value of Parameters 07 - [Subnet Cfg 1] through 10 -
[Subnet Cfg 4] to the desired value for the subnet mask.
Figure 3.6 Example Subnet Mask Parameter Setup Values
3. Reset the module. See
To set a gateway address for the module using parameters
1. Verify that Parameter 02 - [BOOTP] is set to Disabled. This
parameter must be set to Disabled to configure the gateway address
using parameters.
2. Set the value of Parameters 11 - [Gateway Cfg 1] through 14 -
[Gateway Cfg 4] to the IP address of the gateway device.
Figure 3.7 Example Gateway Parameter Setup Values
3. Reset the module. See
Default = 0.0.0.0
255 . 255 . 255 . 255
[Subnet Cfg 1]
[Subnet Cfg 2]
[Subnet Cfg 3]
[Subnet Cfg 4]
Default = 0.0.0.0
255 . 255 . 255 . 255
[Gateway Cfg 1]
[Gateway Cfg 2]
[Gateway Cfg 3]
[Gateway Cfg 4]
