Configuring the Module
3. Select the destination of the data that is input to the drive as Peer A in
Parameter 48 - [Peer A Input].
4. If desired, select the destination of the data to input to the drive as
Peer B in Parameter 49 - [Peer B Input].
5. If the module receives a Logic Command, set the bits in Parameter
50 - [Peer Cmd Mask] that the drive should use. The bit definitions
for the Logic Command word will depend on the drive to which the
module is connected. Refer to
or drive documentation.
6. Set Parameter 56 - [Peer Inp Timeout] to the maximum amount of
time the module will wait for a message before timing out. The
default is 10.00 seconds.
Important: This value must be greater than the product of
Parameter 62 - [Peer Out Time] multiplied by
Parameter 63 - [Peer Out Skip] in the module from
which you are receiving I/O.
For example, if the value of Parameter 62 - [Peer Out Time] is 2.00
and the value of Parameter 63 - [Peer Out Skip] is 2 (2.00 x 2 =
Table 3.J Parameter 48 - [Peer A Input] Setup Values
Value
Description
0
Off (Default)
1
Logic Command/Reference
2 - 5
Datalink A, B, C, or D Input
Table 3.K Parameter 49 - [Peer B Input] Setup Values
Value
Description
0
Off (Default)
1
Logic Command/Reference
2 - 5
Datalink A, B, C, or D Input
!
ATTENTION: If the module receives a Logic Command from both a
Master device and a Peer device, each command bit must have only one
source. This includes the stop bit. The source of command bits set to
“0” will be the Master device. The source of command bits set to “1”
will be the Peer device.
Table 3.L Parameter 50 - [Peer Cmd Mask] Setup Values
Value
Description
0
Ignore this command bit. (Default)
1
Use this command bit.
