Module Parameters
B-9
57
[Peer Inp Enable]
Determines if Peer I/O input is on or off.
Default:
0 = Off
Values:
0 = Off
1 = On
Type:
Read/Write
Reset Required:
No
58
[Peer Inp Status]
Displays the status of the consumed peer input
connection.
Default:
0 = Off
Values:
0 = Off
1 = Waiting
2 = Running
3 = Faulted
Type:
Read Only
59
60
[Peer A Output]
[Peer B Output]
Selects the source of the Peer I/O output data.
The module transmits this data to the network.
Important: Changes to these parameters are
ignored when Parameter 61 - [Peer Out Enable] is
On.
Default:
0 = Off
Values:
0 = Off
1 = Cmd/Ref
2 = Datalink A Input
3 = Datalink B Input
4 = Datalink C Input
5 = Datalink D Input
6 = Datalink A Output
7 = Datalink B Output
8 = Datalink C Output
9 = Datalink D Output
Type:
Read/Write
Reset Required:
No
61
[Peer Out Enable]
Determines if Peer I/O output is on or off.
Default:
0 = Off
Values:
0 = Off
1 = On
Type:
Read/Write
Reset Required:
No
62
[Peer Out Time]
Determines the minimum time that a module will
wait when transmitting data to a peer.
Important: Changes to these parameters are
ignored when Parameter 61 - [Peer Out Enable] is
On.
Default:
10.00 Seconds
Minimum:
0.01 Seconds
Maximum:
10.00 Seconds
Type:
Read/Write
Reset Required:
No
63
[Peer Out Skip]
Determines the maximum time that a module will
wait when transmitting data to a peer. The value of
Parameter 62 - [Peer Out Time] is multiplied by the
value of this parameter to set the time.
Important: Changes to these parameters are
ignored when Parameter 61 - [Peer Out Enable] is
On.
Default:
1
Minimum:
1
Maximum:
16
Type:
Read/Write
Reset Required:
No
64
[Web Enable]
Displays the setting of the Web Pages Switch
(SW2) on the module when the module was last
reset.
Default:
0 = Disabled
Minimum:
0 = Disabled
Maximum:
1 = Enabled
Type:
Read Only
Parameter
No. Name and Description
Details
