Alpha Wire | www.alphawire.com | 1-800-52 ALPHA
Specifications subject to change. For complete specifications and availability, visit www.alphawire.com.
115
Cable > Xtra-Guard > Xtra-Guard Flex > Multiconductor > Unshielded > 300 V
Xtra-Guard® Continuous Flex Data
C-Track or High Flexing Applications Up to 6 Million Flex Life Cycles
300 V Unshielded, Multiconductor
UL CM
UL AWM 2661
CSA AWM I/II A/B FT4
CSA CMG
CE
Operating Temperature
• +5°C to +105°C (flexing)
• -10°C to +105°C (stationary)
Conductor Color Coding
• Chart D (page 519)
• Jacket color: slate
Materials
• Finely stranded tinned copper
conductors
• Lubricated semi-rigid PVC
insulation
• Oil-resistant PVC jacket
Availability
100 ft (30.5 m)
500 ft (152 m)
1000 ft (305 m)
Bulk, cut to length
FIT® Tubing Recommendations
• FIT-FLEX: Highly flexible,
cross-linked silicone rubber
• FIT-650: Chemical/
temperature resistant cross-
linked fluoroelastomer
28 AWG (0.09 mm
2
)
Stranding: 7/36 (7 x 0.13 mm)
Insulation thickness: 0.010 (0.25 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
86002
2
0.154
3.91
0.040
1.02
86003
3
0.160
4.06
0.040
1.02
86004
4
0.170
4.32
0.040
1.02
86005
5
0.180
4.57
0.040
1.02
86007
7
0.203
5.16
0.040
1.02
86012
12
0.263
6.68
0.040
1.02
86018
18
0.262
6.65
0.040
1.02
86025
25
0.309
7.85
0.040
1.02
26 AWG (0.14 mm
2
)
Stranding: 7/34 (7 x 0.16 mm)
Insulation thickness: 0.010 (0.25 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
86102
2
0.162
4.11
0.040
1.02
86103
3
0.168
4.27
0.040
1.02
86104
4
0.179
4.55
0.040
1.02
86105
5
0.191
4.85
0.040
1.02
86107
7
0.217
5.51
0.040
1.02
86112
12
0.283
7.19
0.040
1.02
86118
18
0.282
7.16
0.040
1.02
86125
25
0.335
8.51
0.040
1.02
24 AWG (0.20 mm
2
)
Stranding: 10/34 (10 x 0.16 mm)
Insulation thickness: 0.010 (0.25 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
86202
2
0.172
4.37
0.040
1.02
86203
3
0.179
4.55
0.040
1.02
86204
4
0.191
4.85
0.040
1.02
86205
5
0.205
5.21
0.040
1.02
86207
7
0.233
5.92
0.040
1.02
86212
12
0.307
7.80
0.040
1.02
86218
18
0.307
7.80
0.040
1.02
86225
25
0.376
9.55
0.045
1.14
22 AWG (0.38 mm
2
)
Stranding: 19/34 (19 x 0.16 mm)
Insulation thickness: 0.010 (0.25 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
86302
2
0.188
4.78
0.040
1.02
86303
3
0.197
5.00
0.040
1.02
86304
4
0.211
5.36
0.040
1.02
86305
5
0.227
5.77
0.040
1.02
86307
7
0.260
6.60
0.040
1.02
86312
12
0.347
8.81
0.040
1.02
86318
18
0.347
8.81
0.040
1.02
86325
25
0.426
10.82
0.045
1.14
