Alpha Wire | www.alphawire.com | 1-800-52 ALPHA
Specifications subject to change. For complete specifications and availability, visit www.alphawire.com.
90
Cable > Xtra-Guard > Xtra-Guard 4 > Multipair > Foil Shield > 300 V
Xtra-Guard® 4
Advanced Temperature and Chemical Performance
300 V Foil Shield, Multipair
UL AWM 20237
UL PLTC
CSA AWM I/II A/B FT1
MSHA P-07-KA070017-MSHA
NEC Class 1, Div 2 (22 AWG)
Operating Temperature
• –50°C to +125°C
Conductor Color Coding
• Chart B (page 516)
• Nine jacket colors
(black standard)
• Custom colors available
Materials
• Stranded tinned copper
conductors
• TPE insulation
• TPE jacket
• Aluminum/polyester foil shield,
with 25% overlap and foil
facing inward
• Tinned copper drain wire sized
the same as cable conductors
• Nylon ripcord
Availability
Made to order
1000 ft (305 m) minimum
FIT® Tubing Recommendations
• FIT-600: highly flexible,
cross-linked elastomer
• FIT-400: temperature/chemical
resistant FEP
24 AWG (0.23 mm
2
)
Stranding: 7/32 (7 x 0.20 mm)
Insulation thickness: 0.016 (0.41 mm)
Part No.
Pairs
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
45491
1
0.204
5.18
0.042
1.07
45492
2
0.276
7.01
0.042
1.07
45493
3
0.290
7.37
0.042
1.07
45494
4
0.314
7.98
0.042
1.07
45495
5
0.341
8.66
0.042
1.07
45496
6
0.370
9.40
0.042
1.07
45499
9
0.428
10.87
0.042
1.07
45499/11
11
0.459
11.66
0.042
1.07
45499/15
15
0.516
13.11
0.042
1.07
45499/27
27
0.679
17.25
0.053
1.35
22 AWG (0.35 mm
2
)
Stranding: 7/30 (7 x 0.25 mm)
Insulation thickness: 0.016 (0.41 mm)
Part No.
Pairs
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
45481
1
0.222
5.64
0.045
1.14
45482
2
0.301
7.65
0.045
1.14
45483
3
0.317
8.05
0.045
1.14
45484
4
0.344
8.74
0.045
1.14
45485
5
0.374
9.50
0.045
1.14
45486
6
0.425
10.80
0.055
1.40
45489
9
0.489
12.42
0.055
1.40
45489/11
11
0.525
13.34
0.055
1.40
45489/15
15
0.588
14.94
0.055
1.40
* UL AWM 20237, CSA AWM I/II A/B FT1 only
