Alpha Wire | www.alphawire.com | 1-800-52 ALPHA
Specifications subject to change. For complete specifications and availability, visit www.alphawire.com.
53
22 AWG (0.35 mm
2
)
Stranding: 7/30 (7 x 0.25 mm)
Insulation thickness: 0.010 (0.25 mm)
Part No.
Pairs
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
5481C
1
0.172
4.37
0.032
0.81
5482C
2
0.236
5.99
0.032
0.81
5483C
3
0.249
6.32
0.032
0.81
5484C
4
0.271
6.88
0.032
0.81
5485C
5
0.295
7.49
0.032
0.81
5486C
6
0.320
8.13
0.032
0.81
5489C
9
0.372
9.45
0.032
0.81
5489/11C
11
0.400
10.16
0.032
0.81
5489/15C
15
0.451
11.46
0.032
0.81
5489/19C
19
0.483
12.27
0.032
0.81
5489/27C
27
0.619
15.72
0.053
1.35
Cable > Xtra-Guard > Xtra-Guard 1 > Multipair > Foil Shield > 300 V
Xtra-Guard® 1
High Performance
300 V Foil Shield, Multipair
UL CM
UL AWM 2464 VW-1
CSA CMG FT4
Operating Temperature
• –30°C to +80°C (AWM)
• –30°C to +105°C (CM)
Conductor Color Coding
• 28, 26, 24, 22 AWG: Chart B
(page 516)
• 20, 18 AWG: Chart A (page 516)
• Jacket Colors
• Put-ups: slate
• Bulk: nine colors available
(page 31, minimums
may apply)
Materials
• Stranded tinned copper
conductors
• Premium PVC insulation
• Aluminum/polyester foil shield,
with 25% overlap and foil
facing inward
• Tinned copper drain wire sized
the same as cable conductors
• Nylon ripcord
• Premium PVC jacket
• UV resistant
Availability
100 ft (30.5 m)
500 ft (152 m)
1000 ft (305 m)
Bulk, cut to length
FIT® Tubing Recommendations
• FIT-221: General-purpose,
cross-linked polyolefin (indoor)
• FIT-321: Medium-wall,
adhesive-lined, cross-linked
polyolefin (outdoor)
20 AWG (0.56 mm
2
)
Stranding: 7/28 (7 x 0.32 mm)
Insulation thickness: 0.016 (0.41 mm)
Part No.
Pairs
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
5452C
2
0.302
7.67
0.032
0.81
5453C
3
0.320
8.13
0.032
0.81
5456C
6
0.419
10.64
0.032
0.81
5459C
9
0.491
12.47
0.032
0.81
5459/12C
12
0.549
13.94
0.032
0.81
5459/19C
19
0.689
17.50
0.053
1.35
18 AWG (0.81 mm
2
)
Stranding: 16/30 (16 x 0.25 mm)
Insulation thickness: 0.016 (0.41 mm)
Part No.
Pairs
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
5373C
3
0.352
8.94
0.032
0.81
5376C
6
0.464
11.79
0.032
0.81
