Cable > Xtra-Guard > Xtra-Guard 5 > Multipair > Foil Shield > 300 V
Xtra-Guard® 5
Maximum Temperature and Chemical Performance
300 V Foil Shield, Multipair
UL AWM 20229
UL CMP
CSA CMP FT6
Operating Temperature
• –80°C to +200°C
• –80°C to +150°C (AWM, CMP)
Conductor Color Coding
• Chart A (page 516)
• Nine jacket tints (tan standard)
• Custom colors available
Materials
• Stranded tinned copper
conductors
• FEP insulation
• FEP jacket
• Aluminum/polyester foil shield,
with 25% overlap and foil
facing inward
• Tinned copper drain wire sized
the same as cable conductors
• Aramid fiber ripcord
Availability
Made to order
1000 ft (305 m) minimum
FIT® Tubing Recommendations
• FIT-650: Chemical/temperature
resistant flexible fluoroelastomer
• FIT-400: Temperature/chemical
resistant FEP
24 AWG (0.23 mm
2
)
Stranding: 7/32 (7 x 0.20 mm)
Insulation thickness: 0.010 (0.25 mm)
Part No.
Pairs
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
55491
1
0.154
3.91
0.027
0.69
55492
2
0.210
5.33
0.027
0.69
55493
3
0.222
5.64
0.027
0.69
55496
6
0.284
7.21
0.027
0.69
55499
9
0.329
8.36
0.027
0.69
55499/11
11
0.355
9.02
0.027
0.69
22 AWG (0.35 mm
2
)
Stranding: 7/30 (7 x 0.25 mm)
Insulation thickness: 0.010 (0.25 mm)
Part No.
Pairs
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
55481
1
0.166
4.22
0.027
0.69
55482
2
0.230
5.84
0.027
0.69
55483
3
0.243
6.17
0.027
0.69
55486
6
0.313
7.95
0.027
0.69
55489
9
0.364
9.25
0.027
0.69
55489/12
12
0.407
10.34
0.027
0.69
20 AWG (0.56 mm
2
)
Stranding: 7/28 (7 x 0.32
mm)
Insulation thickness: 0.010 (0.25 mm)
Part No.
Pairs
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
55451
1
0.182
4.62
0.027
0.69
55452
2
0.256
6.50
0.027
0.69
55453
3
0.271
6.88
0.027
0.69
55455
5
0.324
8.23
0.027
0.69
55456
6
0.353
8.97
0.027
0.69
55459
9
0.412
10.46
0.027
0.69
55459/12
12
0.461
11.71
0.027
0.69
18 AWG (0.90 mm
2
)
Stranding: 7/26 (7 x 0.40 mm)
Insulation thickness: 0.010 (0.25 mm)
Part No.
Pairs
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
55371
1
0.202
5.13
0.027
0.69
55372
2
0.289
7.34
0.027
0.69
55373
3
0.306
7.77
0.027
0.69
55376
6
0.402
10.21
0.027
0.69
55379
9
0.472
11.99
0.027
0.69
