Alpha Wire | www.alphawire.com | 1-800-52 ALPHA
Specifications subject to change. For complete specifications and availability, visit www.alphawire.com.
114
Cable > Xtra-Guard > Xtra-Guard Flex > Multiconductor > Braid Shield > 600 V
Xtra-Guard® Continuous Flex Control
C-Track or High Flexing Applications Up to 14 Million Flex Life Cycles
600 V Shielded, Multiconductor
UL AWM 2587
CSA AWM I/II A/B FT1
CE
Operating Temperature
• -5°C to +90°C (flexing)
• -40°C to +90°C (stationary)
Conductor Color Coding
• Numbered red conductors
• 1 yellow/green ground
conductor
• Jacket color: black
Materials
• Finely stranded bare copper
conductors
• Lubricated PVC insulation
• Tinned copper braid shield,
85% coverage
• PVC inner jacket
• Oil-resistant PVC jacket
Availability
100 ft (30.5 m)
500 ft (152 m)
1000 ft (305 m)
Bulk, cut to length
FIT® Tubing Recommendations
• FIT-FLEX: Highly flexible,
cross-linked silicone rubber
• FIT-650: Chemical/
temperature resistant cross-
linked fluoroelastomer
12 AWG (3.35 mm
2
)
Stranding: 413/38 (413 x 0.10 mm)
Insulation thickness: 0.022 (0.56 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
85204CY
4
0.641
16.28
0.075
1.90
85207CY
7
0.836
21.23
0.100
2.54
10 AWG (5.34 mm
2
)
Stranding: 658/38 (658 x 0.10 mm)
Insulation thickness: 0.022” (0.56 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
85104CY
4
0.707
17.96
0.070
1.78
85107CY
7
0.947
24.05
0.100
2.54
8 to 2 AWG (8.62 to 33.86 mm
2
)
Part No.
Conductors
Wire Size
Stranding
Nominal Diameter
Jacket Thickness
Insulation Thickness
AWG
mm
2
AWG
mm
Inch
mm
Inch
mm
Inch
mm
85904CY
4
8
8.62
266/32
266 x 0.20
0.882
22.40
0.085
2.16
0.032
0.81
85704CY
4
6
13.38
413/32
413 x 0.20
1.066
27.08
0.085
2.16
0.047
1.19
85504CY
4
4
21.55
665/32
665 x 0.20
1.227
31.17
0.085
2.16
0.047
1.19
85304CY
4
2
33.86
1045/32
1045 x 0.20
1.431
36.35
0.095
2.41
0.047
1.19
