Alpha Wire | www.alphawire.com | 1-800-52 ALPHA
Specifications subject to change. For complete specifications and availability, visit www.alphawire.com.
112
Cable > Xtra-Guard > Xtra-Guard Flex > Multiconductor > Unshielded > 600 V
Xtra-Guard® Continuous Flex Control
C-Track or High Flexing Applications Up to 14 Million Flex Life Cycles
600 V Unshielded, Multiconductor
UL AWM 2587
CSA AWM I/II A/B FT1
CE
Operating Temperature
• -5°C to +90°C (flexing)
• -40°C to +90°C (stationary)
Conductor Color Coding
• Numbered red conductors
• 1 yellow/green ground
conductor
• Jacket color: black
Materials
• Finely stranded bare copper
conductors
• Lubricated PVC insulation
• Oil-resistant PVC jacket
12 AWG (3.35 mm
2
)
Stranding: 413/38 (413 x 0.10 mm)
Insulation thickness: 0.022 (0.56 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
85204
4
0.527
13.39
0.070
1.78
85207
7
0.729
18.52
0.100
2.54
10 AWG (5.34 mm
2
)
Stranding: 658/38 (658 x 0.10 mm)
Insulation thickness: 0.022” (0.56 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
85104
4
0.590
14.99
0.070
1.78
85107
7
0.816
20.73
0.100
2.54
Availability
100 ft (30.5 m)
500 ft (152 m)
1000 ft (305 m)
Bulk, cut to length
FIT® Tubing Recommendations
• FIT-FLEX: Highly flexible,
cross-linked silicone rubber
• FIT-650: Chemical/
temperature resistant cross-
linked fluoroelastomer
8 to 2 AWG (8.62 to 33.86 mm
2
)
Part No.
Conductors
Wire Size
Stranding
Nominal Diameter
Jacket Thickness
Insulation Thickness
AWG
mm
2
AWG
mm
Inch
mm
Inch
mm
Inch
mm
85904
4
8
8.62
266/32
266 x 0.20
0.721
18.31
0.070
1.78
0.032
0.81
85704
4
6
13.38
413/32
413 x 0.20
0.935
23.75
0.085
2.16
0.047
1.19
85504
4
4
21.55
665/32
665 x 0.20
1.076
27.33
0.085
2.16
0.047
1.19
85304
4
2
33.86
1045/32
1045 x 0.20
1.250
31.75
0.085
2.16
0.047
1.19
