Cable > Xtra-Guard > Xtra-Guard 3 > Multiconductor > Foil Shielded > 300 V
Xtra-Guard® 3
Direct Burial
300 V Foil Shield, Multiconductor
Operating Temperature
• –30°C to +80°C
Conductor Color Coding
• Chart D (page 519)
• Nine jacket colors
(black standard)
• Custom colors available
Materials
• Stranded tinned copper
conductors
• Premium PVC insulation
• Specially formulated
polyethylene jacket
• UV resistant
• Aluminum/polyester foil shield,
with 25% overlap and foil
facing inward
• Tinned copper drain wire sized
the same as cable conductors
• Nylon ripcord
Availability
Made to order
1000 ft (305 m) minimum
FIT® Tubing Recommendations
• FIT-700: Bonding,
thermoplastic adhesive lined,
cross-linked polyolefin
18 AWG (0.81 mm
2
)
Stranding: 16/30 (16 x 0.25 mm)
Insulation thickness: 0.016 (0.41 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
35382
2
0.229
5.82
0.032
0.81
35383
3
0.241
6.12
0.032
0.81
35384
4
0.262
6.65
0.032
0.81
35386
6
0.309
7.85
0.032
0.81
35388
8
0.334
8.48
0.032
0.81
35390
10
0.387
9.83
0.032
0.81
35390/15
15
0.434
11.02
0.032
0.81
35390/20
20
0.485
12.32
0.032
0.81
35390/25
25
0.587
14.91
0.053
1.35
16 AWG (1.23 mm
2
)
Stranding: 19/0.0117 (19 x 0.29 mm)
Insulation thickness: 0.016 (0.41 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
35362
2
0.253
6.43
0.032
0.81
35363
3
0.267
6.78
0.032
0.81
35364
4
0.291
7.39
0.032
0.81
35366
6
0.345
8.76
0.032
0.81
35368
8
0.374
9.50
0.032
0.81
35370
10
0.435
11.05
0.032
0.81
35370/15
15
0.489
12.42
0.032
0.81
35370/20
20
0.589
14.96
0.053
1.35
35370/25
25
0.659
16.74
0.053
1.35
