Xtra-guard® 2 – Northern Connectors Alpha Wire XTRA-GUARD Performance Cable User Manual
Page 35
Alpha Wire | www.alphawire.com | 1-800-52 ALPHA
Specifications subject to change. For complete specifications and availability, visit www.alphawire.com.
63
Cable > Xtra-Guard > Xtra-Guard 2 > Multiconductor > Foil Shielded > 600 V
Xtra-Guard® 2
Oil and Abrasion Resistant
600 V Foil Shielded, Multiconductor
UL AWM 20952 VW-1
CSA AWM I/II A/B FT1
Operating Temperature
• –30°C to +105°C
Conductor Color Coding
• Chart E (page 520)
• Nine jacket colors
(black standard)
• Custom colors available
Materials
• Stranded tinned copper
conductors
• Premium PVC insulation
• Specially formulated
polyurethane jacket
• UV resistant
• Aluminum/polyester/aluminum
foil shield, with 25% overlap
and foil facing inward
• Tinned copper drain wire sized
the same as cable conductors
• Nylon ripcord
Availability
Made to order
1000 ft (305 m) minimum
FIT® Tubing Recommendations
• FIT-750: Bonding adhesive lined,
cross-linked polyolefin
18 AWG (0.81 mm
2
)
Stranding: 16/30 (16 x 0.25 mm)
Insulation thickness: 0.032 (0.81 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
25430/2
2
0.356
9.04
0.063
1.60
25430/3
3
0.373
9.47
0.063
1.60
25430/4
4
0.403
10.24
0.063
1.60
25430/5
5
0.436
11.07
0.063
1.60
25430/7
7
0.470
11.94
0.063
1.60
25430/9
9
0.539
13.69
0.063
1.60
25430/12
12
0.595
15.11
0.063
1.60
25430/15
15
0.647
16.43
0.063
1.60
25430/19
19
0.690
17.53
0.063
1.60
16 AWG (1.23 mm
2
)
Stranding: 19/0.0117 (19 x 0.29 mm)
Insulation thickness: 0.032 (0.81 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
25440/2
2
0.380
9.65
0.063
1.60
25440/3
3
0.399
10.13
0.063
1.60
25440/4
4
0.432
10.97
0.063
1.60
25440/5
5
0.468
11.89
0.063
1.60
25440/7
7
0.506
12.85
0.063
1.60
25440/9
9
0.583
14.81
0.063
1.60
25440/12
12
0.645
16.38
0.063
1.60
25440/15
15
0.702
17.83
0.063
1.60
14 AWG (2.08 mm
2
)
Stranding: 41/30 (41 x 0.25 mm)
Insulation thickness: 0.032 (0.81 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
25450/2
2
0.410
10.41
0.063
1.60
25450/3
3
0.432
10.97
0.063
1.60
25450/4
4
0.468
11.89
0.063
1.60
25450/5
5
0.509
12.93
0.063
1.60
25450/7
7
0.551
14.00
0.063
1.60
25450/9
9
0.638
16.21
0.063
1.60
25450/12
12
0.707
17.96
0.063
1.60
25450/15
15
0.771
19.58
0.063
1.60
