62
Cable > Xtra-Guard > Xtra-Guard 2 > Multiconductor > Foil Shielded > 300 V
Xtra-Guard® 2
Oil and Abrasion Resistant
300 V Foil Shielded, Multiconductor
UL AWM 20668 VW-1
CSA AWM I/II A/B FT1
Operating Temperature
• –30°C to +90°C
Conductor Color Coding
• 24, 22 AWG: Chart E (page 520)
• 20, 18, 16 AWG: Chart D
(page 519)
• Nine jacket colors
(black standard)
• Custom colors available
Materials
• Stranded tinned copper
conductors
• Premium PVC insulation
• Specially formulated
polyurethane jacket
• UV resistant
• Aluminum/polyester/aluminum
foil shield, with 25% overlap
and foil facing inward
• Tinned copper drain wire sized
the same as cable conductors
• Nylon ripcord
Availability
Made to order
1000 ft (305 m) minimum
FIT® Tubing Recommendations
• FIT-750: Bonding adhesive lined,
cross-linked polyolefin
18 AWG (0.81 mm
2
)
Stranding: 16/30 (16 x 0.25 mm)
Insulation thickness: 0.016 (0.41 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
25382
2
0.230
5.84
0.032
0.81
25382/1*
2
0.230
5.84
0.032
0.81
25383
3
0.242
6.14
0.032
0.81
25383/1*
3
0.242
6.14
0.032
0.81
25384
4
0.263
6.68
0.032
0.81
25386
6
0.311
7.90
0.032
0.81
25388
8
0.336
8.53
0.032
0.81
25390
10
0.388
9.86
0.032
0.81
25390/15
15
0.437
11.10
0.032
0.81
25390/20
20
0.488
12.40
0.032
0.81
25390/25
25
0.588
14.94
0.053
1.35
25390/30
30
0.621
15.77
0.053
1.35
25390/40
40
0.692
17.58
0.053
1.35
25390/50
50
0.762
19.35
0.053
1.35
16 AWG (1.23 mm
2
)
Stranding: 19/0.0117 (19 x 0.29 mm)
Insulation thickness: 0.016 (0.41 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
25362
2
0.254
6.45
0.032
0.81
25362/1*
2
0.254
6.45
0.032
0.81
25363
3
0.268
6.81
0.032
0.81
25363/1*
3
0.268
6.81
0.032
0.81
25364
4
0.292
7.42
0.032
0.81
25366
6
0.347
8.81
0.032
0.81
25368
8
0.376
9.55
0.032
0.81
25370
10
0.436
11.07
0.032
0.81
25370/15
15
0.492
12.50
0.032
0.81
25370/20
20
0.593
15.06
0.053
1.35
25370/25
25
0.660
16.76
0.053
1.35
25370/30
30
0.698
17.73
0.053
1.35
25370/40
40
0.779
19.79
0.083
2.11
25370/50
50
0.921
23.39
0.083
2.11
*Conductors color-coded per international standards: brown, blue, green/yellow.
*Conductors color-coded per international standards: brown, blue, green/yellow.
