Cable > Xtra-Guard > Xtra-Guard 1 > Multiconductor > Foil Shielded > 300 V
Xtra-Guard® 1
High Performance
300 V Foil Shielded, Multiconductor
22 AWG (0.35 mm
2
)
Stranding: 7/30 (7 x 0.25 mm)
Insulation thickness: 0.010 (0.25 mm)
Part Number
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
5192C
2
0.172
4.37
0.032
0.81
5193C
3
0.180
4.57
0.032
0.81
5194C
4
0.193
4.90
0.032
0.81
5196C
6
0.223
5.66
0.032
0.81
5198C
8
0.239
6.07
0.032
0.81
5199/10C
10
0.272
6.91
0.032
0.81
5199/15C
15
0.303
7.70
0.032
0.81
5199/20C
20
0.335
8.51
0.032
0.81
5199/25C
25
0.372
9.45
0.032
0.81
5199/30C
30
0.393
9.98
0.032
0.81
5199/40C
40
0.438
11.13
0.032
0.81
5199/50C
50
0.482
12.24
0.032
0.81
5199/60C
60
0.522
13.26
0.032
0.81
5199/70C
70
0.606
15.39
0.053
1.35
20 AWG (0.56 mm
2
)
Stranding: 7/28 (7 x 0.32
mm)
Insulation thickness: 0.016 (0.41 mm)
Part Number
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
5462C
2
0.212
5.38
0.032
0.81
5463C
3
0.223
5.66
0.032
0.81
5464C
4
0.242
6.15
0.032
0.81
5466C
6
0.284
7.21
0.032
0.81
5468C
8
0.306
7.77
0.032
0.81
5470C
10
0.352
8.94
0.032
0.81
5470/15C
15
0.395
10.03
0.032
0.81
5470/20C
20
0.441
11.20
0.032
0.81
5470/25C
25
0.492
12.50
0.032
0.81
5470/30C
30
0.521
13.23
0.032
0.81
5470/40C
40
0.626
15.90
0.053
1.35
5470/50C
50
0.688
17.48
0.053
1.35
UL CM
UL AWM 2464 VW-1
CSA CMG FT4
Operating Temperature
• –30°C to +80°C (AWM)
• –30°C to +105°C (CM)
Conductor Color Coding
• 28, 26, 24, 22 AWG: Chart E
(page 520)
• 20, 18, 16 AWG: Chart D (page 519)
• Jacket Colors
• Put-ups: slate
• Bulk: nine colors available
(page 31, minimums
may apply)
Materials
• Stranded tinned copper
conductors
• Premium PVC insulation
• Aluminum/polyester foil shield,
with 25% overlap and foil
facing inward
• Tinned copper drain wire sized
the same as cable conductors
• Nylon ripcord
• Premium PVC jacket
• UV resistant
Availability
100 ft (30.5 m)
500 ft (152 m)
1000 ft (305 m)
Bulk, cut to length
FIT® Tubing Recommendations
• FIT-221: General-purpose,
cross-linked polyolefin (indoor)
• FIT-321: Medium-wall,
adhesive-lined, cross-linked
polyolefin (outdoor)
