Cable > Xtra-Guard > Xtra-Guard 1 > Multiconductor > Foil Shielded > 300 V
Xtra-Guard® 1
High Performance
300 V Foil Shielded, Multiconductor
UL CM
UL AWM 2464 VW-1
CSA CMG FT4
Operating Temperature
• –30°C to +80°C (AWM)
• –30°C to +105°C (CM)
Conductor Color Coding
• 28, 26, 24, 22 AWG: Chart E
(page 520)
• 20, 18, 16 AWG: Chart D (page 519)
• Jacket Colors
• Put-ups: slate
• Bulk: nine colors available
(page 31, minimums
may apply)
Materials
• Stranded tinned copper
conductors
• Premium PVC insulation
• Aluminum/polyester foil shield,
with 25% overlap and foil
facing inward
• Tinned copper drain wire sized
the same as cable conductors
• Nylon ripcord
• Premium PVC jacket
• UV resistant
Availability
100 ft (30.5 m)
500 ft (152 m)
1000 ft (305 m)
Bulk, cut to length
FIT® Tubing Recommendations
• FIT-221: General-purpose,
cross-linked polyolefin (indoor)
• FIT-321: Medium-wall,
adhesive-lined, cross-linked
polyolefin (outdoor)
18 AWG (0.81 mm
2
)
Stranding: 16/30 (16 x 0.25 mm)
Insulation thickness: 0.016 (0.41 mm)
Part Number
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
5382C
2
0.230
5.84
0.032
0.81
5382/1C*
2
0.230
5.84
0.032
0.81
5383C
3
0.242
6.15
0.032
0.81
5383/1C*
3
0.242
6.15
0.032
0.81
5384C
4
0.263
6.68
0.032
0.81
5386C
6
0.311
7.90
0.032
0.81
5388C
8
0.336
8.53
0.032
0.81
5390C
10
0.388
9.86
0.032
0.81
5390/15C
15
0.437
11.10
0.032
0.81
5390/20C
20
0.488
12.40
0.032
0.81
5390/25C
25
0.588
14.94
0.053
1.35
5390/30C
30
0.621
15.77
0.053
1.35
5390/40C
40
0.692
17.58
0.053
1.35
5390/50C
50
0.762
19.35
0.053
1.35
5390/60C
60
0.885
22.48
0.083
2.11
*Conductors color-coded per international standards: brown, blue, green/yellow.
16 AWG (1.23 mm
2
)
Stranding: 19/0.0117 (19 x 0.29 mm)
Insulation thickness: 0.016 (0.41 mm)
Part Number
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
5362C
2
0.254
6.45
0.032
0.81
5362/1C*
2
0.254
6.45
0.032
0.81
5363C
3
0.268
6.81
0.032
0.81
5363/1C*
3
0.268
6.81
0.032
0.81
5364C
4
0.292
7.42
0.032
0.81
5366C
6
0.347
8.81
0.032
0.81
5368C
8
0.376
9.55
0.032
0.81
5370C
10
0.436
11.07
0.032
0.81
5370/15C
15
0.492
12.50
0.032
0.81
5370/20C
20
0.593
15.06
0.053
1.35
5370/25C
25
0.660
16.76
0.053
1.35
5370/30C
30
0.698
17.73
0.053
1.35
5370/40C
40
0.779
19.79
0.083
2.11
*Conductors color-coded per international standards: brown, blue, green/yellow.
