Cable > Xtra-Guard > Xtra-Guard 4 > Multiconductor > Supra-Shield Foil/Braid > 600 V
Xtra-Guard® 4
Advanced Temperature and Chemical Performance
600 V Supra-Shield® Foil/Braid, Multiconductor
UL AWM 20238
UL TC, WTTC
CSA AWM I/II A/B FT1
MSHA P-07-KA070017-MSHA
NEC Class 1, Div 2
Operating Temperature
• –50°C to +125°C
Conductor Color Coding
• Chart E (page 520)
• Nine jacket colors
(black standard)
• Custom colors available
Materials
• Stranded tinned copper
conductors
• TPE insulation
• TPE jacket
• Supra-Shield foil + braid shield:
Aluminum/polyester/aluminum
foil with 25% overlap min.
Tinned copper drain wire sized
the same as conductors
Tinned copper braid, 70%
coverage min.
• Nylon ripcord
Availability
Made to order
1000 ft (305 m) minimum
FIT® Tubing Recommendations
• FIT-600: highly flexible,
cross-linked elastomer
• FIT-400: temperature/chemical
resistant FEP
18 AWG (0.81 mm
2
)
Stranding: 16/30 (16 x 0.25 mm)
Insulation thickness: 0.032 (0.81 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
45522
2
0.364
9.25
0.055
1.40
45523
3
0.381
9.68
0.055
1.40
45524
4
0.411
10.44
0.055
1.40
45525
5
0.444
11.28
0.055
1.40
45527
7
0.478
12.14
0.055
1.40
45529
9
0.567
14.40
0.065
1.65
45529/12
12
0.623
15.82
0.065
1.65
16 AWG (1.23 mm
2
)
Stranding: 19/0.0117 (19 x 0.29 mm)
Insulation thickness: 0.032 (0.81 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
45532
2
0.388
9.86
0.055
1.40
45533
3
0.407
10.34
0.055
1.40
45534
4
0.440
11.18
0.055
1.40
45535
5
0.476
12.09
0.055
1.40
45537
7
0.514
13.06
0.055
1.40
45539
9
0.611
15.52
0.065
1.65
45539/12
12
0.679
17.25
0.065
1.65
14 AWG (2.08 mm
2
)
Stranding: 41/30 (41 x 0.25 mm)
Insulation thickness: 0.032 (0.81 mm)
Part No.
Conductors
Nominal Diameter
Jacket Thickness
Inch
mm
Inch
mm
45542
2
0.418
10.62
0.055
1.40
45543
3
0.440
11.18
0.055
1.40
45544
4
0.476
12.09
0.055
1.40
45545
5
0.517
13.13
0.055
1.40
45547
7
0.579
14.71
0.065
1.65
45549
9
0.672
17.07
0.065
1.65
