Lenze · E94AYCER communication module (PROFINET®) · Communication Manual · DMS 9.0 EN · 12/2013 · TD17
97
14 Parameter reference
14.2 Parameters of the communication module for slot MXI1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13880
14 re-run aborts existing
15 got release.ind
16 device passivated
17 device / AR removed
18 protocol violation
19 NARE error
20 RPC-Bind error
21 RPC-Connect error
22 RPC-Read error
23 RPC-Write error
24 RPC-Control error
25 forbidden pull or plug after check.rsp and before in-data.ind
26 AP removed
27 link "down"
28 could not register multicast-mac
29 not synchronized (cannot start companion-ar)
30 wrong topology (cannot start companion-ar)
31 dcp, station-name changed
32 dcp, reset to factory-settings
33 cannot start companion-AR because a 0x8ipp submodule in the first AR...
• has appl-ready-pending (erroneous parameterisation)
• is locked (no parameterisation)
• is wrong or pulled (no parameterisation)
34 no irdata record yet
35 ownership of physical device
Value Meaning
Parameter | Name:
C13880 | Monitoring Reaction
Data type: UNSIGNED_8
Index: 10695 = 0x29C7
The action set in subcode 1 is executed when the node detects that it is no longer in the "Data_Exchange" state.
• Please also observe the notes provided in code C13881 .
• A change in the monitoring response becomes immediately effective.
 Interruption of PROFINET communication ( 75)
Selection list
0 No response
1 Fault
3 Quick stop by trouble
4 Warning Locked
6 Information
Subcodes Lenze setting Info
C13880/1 0: No Response
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
