13
Error messages
13.1
Short overview of the PROFINET error messages
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
13
Error messages
This chapter supplements the error list for the Servo Drive 9400 contained in the reference manual
and in the »Engineer« online help with the error messages of the communication module.
13.1
Short overview of the PROFINET error messages
The following table contains all error messages of the communication module in numerical order of
the error numbers. Moreover the preset error response and - if applicable - the parameters for
setting the error response are specified.
Tip!
If you click on the cross-reference in the first column, you will get a detailed description
(causes and remedies) of the corresponding error message.
Reference manual / »Engineer« online help for Servo Drive 9400
Here you will find general information on diagnostics & fault analysis and on error
messages.
Error number
Designation
Response (Lenze setting)
Adjustable in
hex
dec
13129009
PROFINET: Memory: No access
6: Information
-
13129010
PROFINET: Memory: Read error
6: Information
-
13129011
PROFINET: Memory: Write error
6: Information
-
13131792
PROFINET: Restart by watchdog reset
1: No Response
-
13131793
PROFINET: Internal error
1: No Response
-
13132032
PROFINET: Internal error
1: No Response
-
13132033
PROFINET: Internal error
1: No Response
-
13132048
PROFINET: Internal mapping error
4: Warning locked
-
13132831
PROFINET: Invalid parameter set
1: No Response
-
13132832
PROFINET: Error: Lenze setting loaded
1: No Response
-
13132848
PROFINET: Invalid module configuration
6: Information
-
13133057
PROFINET: Invalid READ.request during parameter access
4: Warning locked
-
13133058
PROFINET: Invalid WRITE.request during parameter access
4: Warning locked
-
13133059
PROFINET: Data output status bad
4: Warning locked
-
13133106
PROFINET: Invalid station name
1: No Response
-
13133107
PROFINET: Invalid IP parameters
1: No Response
-
13133328
PROFINET: Safety communication timeout
4: Warning locked
-
13133329
PROFINET: Safety parameter timeout
4: Warning locked
-
13133330
PROFINET: Safety init error
4: Warning locked
-
13133331
PROFINET: Safety connect error
5: Warning
-
13133392
PROFINET: Internal error
6: Information
-
13140273
PROFINET: "Data_Exchange" status quit
0: No Response
/
