14 Parameter reference
14.2 Parameters of the communication module for slot MXI1
94
Lenze · E94AYCER communication module (PROFINET®) · Communication Manual · DMS 9.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13852
C13853
C13861
Parameter | Name:
C13852 | All words to standard device
Data type: UNSIGNED_16
Index: 10723 = 0x29E3
Display of the process data words 1 ... 32, which are transmitted from the communication module to the drive.
Display range
(min. value | unit | max. value)
0 65535
Subcodes Info
C13852/1
...
C13852/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13853 | All words from standard device
Data type: UNSIGNED_16
Index: 10722 = 0x29E2
Display of the process data words 1 ... 32, which are transmitted from the drive to the communication module.
Display range
(min. value | unit | max. value)
0 65535
Subcodes Info
C13853/1
...
C13853/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13861 | Bus state
Data type: UNSIGNED_16
Index: 10714 = 0x29DA
Bit-coded display of current bus status
 Querying the current bus status ( 81)
Value is bit-coded:
Bit 0 Reserved
... ...
Bit 3 Reserved
Bit 4 Bit 4
Bit 5 Bit 5
Bit 6 Reserved
... ...
Bit 15 Reserved
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
