4 Technical data
4.1 General data and operating conditions
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4 Technical data
4.1 General data and operating conditions
Range Values
Order designation E94AYCER
Communication profile PROFINET
Communication medium S/FTP (Screened Foiled Twisted Pair, ISO/IEC 11801 or EN 50173), CAT 5e
Interface for communication RJ45: Standard Ethernet (in accordance with IEEE 802.3), 100Base-TX (Fast
Ethernet)
Network topology Tree, star, and line
Type of node IO device with real time (RT) communication properties
Number of device nodes Max. 255 in the subnetwork
Max. cable length 100 m
PNO identification number 0x0106
Device identification (Device ID) 0x9400
TCP port 9410
Baud rate 100 Mbps
Switching method "Store and forward"
Switch latency Approx. 125 μs at max. telegram length
Voltage supply External supply via a separate power supply unit
+: U = 24 V DC (20.4 V ... 28.8 V), I = 130 mA
- : Reference potential for external voltage supply
Conformities, approvals • CE
• UL
(see also hardware manual)

Servo Drives 9400 hardware manual
Here you can find the ambient conditions and data on the electromagnetic compatibility
(EMC), which also apply to the communication module.
