6 Commissioning
6.3 Setting the station name
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6.3 Setting the station name
The station name currently used is shown in code C13864 / C14864 .
The station name ...
• is required for unambiguous addressing of the Servo Drive 9400 by the IO controller.
• can either be assigned by the IO controller via PROFINET or set manually in the »Engineer«.
• has to be allocated in accordance with the PROFINET specification:
• 1 or several labels separated by ".".
• Max. length per label: 63 characters
• Max. total length: 240 characters
• Permissible characters: [a ... z], [0 ... 9], [.], [-]
• Labels must not begin or end with [-].
• Prohibited syntax:
• "n.n.n.n" (n = 0 ... 999)
• "port-xyz" (x, y, z = 0 ... 9)
• "port-xyz-abcde" (a, b, c, d, e, x, y, z = 0 ... 9)

Note!
• The "Node blinking test" PROFINET function by means of which an accessible field
device can be identified is supported. During execution of the function, the red LED
ME ( Module status displays ( 78) ) blinks.
• Operation of PROFINET requires a valid station name.
• In the case of impermissible settings, the red BE (
Fieldbus status displays ( 79) ) blinks
and the error message PROFINET: Invalid station name [0x00c86532] ( 86) is output.
The communication module then continues to work internally with the name deleted.
• If the station name is assigned by the IO controller via PROFINET or via the PROFINET
configurator of the »Engineer«, changes will become effective immediately.
