13 Error messages
13.2 Possible causes and remedies
86
Lenze · E94AYCER communication module (PROFINET®) · Communication Manual · DMS 9.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
PROFINET: Invalid module configuration [0x00c86430]
PROFINET: Invalid READ.request during parameter access [0x00c86501]
PROFINET: Invalid WRITE.request during parameter access [0x00c86502]
PROFINET: Data output status bad [0x00c86503]
PROFINET: Invalid station name [0x00c86532]
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
A module or submodule does not comply with the
configuration of the Siemens »STEP7« project.
Check/correct configuration.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
• During the parameter access to data set 47, the
controller has sent an invalid READ.request.
• When reading back the data, the IO Controller has
requested a data length (number of data bytes) that is
to small.
Check/correct configuration.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
• During the parameter access to data set 47, the
controller has sent an invalid WRITE.request.
• When reading back the data, the IO Controller has
requested a data length (number of data bytes) that is
to small.
Check/correct configuration.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Output data invalid.
Connection to the Siemens Controller has been
interrupted.
• Check cables and terminals.
• Plug in the network cable on the PROFINET terminal
X241/X242.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Station name is not PROFINET-compliant. Use a PROFINET-compliant station name.
 Setting the station name ( 35)
