Installation

5.1

Mechanical installation

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

5.1

Mechanical installation

5.1.1

Assembly

[5-1]

Assembly

5.1.2

Disassembly

[5-2]

Disassembly

Note!

A safety bus system (PROFIsafe) can only be operated via the upper module slot (MXI1)

of the Servo Drive 9400.

E94YCXX001G

E94AYCXX001H
