13 Error messages
13.2 Possible causes and remedies
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
PROFINET: Internal error [0x00c86100]
PROFINET: Internal error [0x00c86101]
PROFINET: Internal mapping error [0x00c86110]
PROFINET: Invalid parameter set [0x00c8641f]
PROFINET: Error: Lenze setting loaded [0x00c86420]
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Internal error Send communication module together with a
description of the fault to Lenze.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Internal error Send communication module together with a
description of the fault to Lenze.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The selected PDO mapping is invalid:
• An object not supporting the required properties has
been specified.
• More than 64 bytes of data have been mapped.
Repeat PDO mapping ( 53) .
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
No active parameter set could be loaded. Download application again (including module)
If this happens repeatedly, send the communication
module together with a description of the fault to Lenze.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Access to parameter set in memory module via standard
device was not successful.
Download application again (including module)
If this happens repeatedly, send the communication
module together with a description of the fault to Lenze.
