13 Error messages
13.2 Possible causes and remedies
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
PROFINET: Invalid IP parameters [0x00c86533]
PROFINET: Safety communication timeout [0x00c86610]
PROFINET: Safety parameter timeout [0x00c86611]
PROFINET: Safety init error [0x00c86612]
PROFINET: Safety connect error [0x00c86613]
PROFINET: Internal error [0x00c86650]
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Incorrect IP parameters (IP address, subnet mask,
gateway address).
Correct IP parameters.
 Setting the IP configuration ( 37)
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Communication to the SM30x safety module is
disrupted.
Check if the SM30x safety module is plugged in and
supplied with voltage.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The SM30x safety module does not respond to a
PROFISafe parameterisation telegram (PRM data) within
a given time interval (200 ms).
Check if the SM30x safety module is plugged in and
supplied with voltage.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Communication to the SM30x safety module could not
be initialised correctly.
Send communication module together with a
description of the fault to Lenze.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Communication to the IO controller is disrupted. Check if the SM30x safety module is plugged in and
supplied with voltage.
Response (Lenze setting printed in bold) Setting: not possible
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Internal error Send communication module together with a
description of the fault to Lenze.
