6 Commissioning
6.4 Setting the IP configuration
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6.4 Setting the IP configuration
The IP configuration is required for addressing the Servo Drive 9400 in the PROFINET network. For
this purpose, an IP address, subnet mask and gateway address have to be allocated.
If no PROFINET network or IO controller is available yet, you can allocate the IP address, subnet
mask, and gateway address for the communication module by using the following options:
• Setting via the PROFINET configurator of the »Engineer« ( 38)
• Setting via codes in the »Engineer« ( 40)
• Setting via Siemens »STEP7« (»HW Konfig«) ( 43)
• Setting via the Siemens »Primary Setup Tool« ( 47)

Note!
• If the IP parameters are assigned by the IO Controller via the PROFINET, the PROFINET
configurator of the »Engineer«, Siemens »STEP7« or the Siemens »Primary Setup
Tool«, the changes become effective immediately and are saved with mains failure
protection.
• The assignment of invalid combinations of the IP address, subnet mask, and gateway
address can have the consequence that no connection to PROFINET can be
established.
• In the case of impermissible settings, the red LED BE ( Fieldbus status displays ( 79) )
blinks and the error message PROFINET: Invalid IP parameters [0x00c86533] ( 87) is
output.
