Lenze · E94AYCER communication module (PROFINET®) · Communication Manual · DMS 9.0 EN · 12/2013 · TD17

109

14

Parameter reference

14.3

Parameters of the communication module for slot MXI2

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

C14900

C14901

C14902

C14910

C14911

C14912

C14913

Parameter | Name:

C14900 | Firmware product type

Data type: VISIBLE_STRING

Index: 9675 = 0x25CB

The code contains a string with a length of 8 characters. The identification code "E94AFCER" is displayed.

Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT

Parameter | Name:

C14901 | Firmware compilation date

Data type: VISIBLE_STRING

Index: 9674 = 0x25CA

The code contains a string with a length of 20 characters. The software creation date ("MMM DD YYYY") and time

("hh:mm:ss") are displayed (e.g. "Mar 21 2005 12:31:21").

Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT

Parameter | Name:

C14902 | Firmware version

Data type: VISIBLE_STRING

Index: 9673 = 0x25C9

The code contains a string with a length of 8 characters. The identification code is displayed (e.g. "01.10.09").

Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT

Parameter | Name:

C14910 | I&M1 system designation

Data type: VISIBLE_STRING

Index: 9665 = 0x25C1

Input/output of the I&M1 plant identification code

The Lenze setting shows an empty string.

Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT

Parameter | Name:

C14911 | I&M1 installation site

Data type: VISIBLE_STRING

Index: 9664 = 0x25C0

Input/output of the I&M1 location identification code

The Lenze setting shows an empty string.

Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT

Parameter | Name:

C14912 | I&M2 installation date

Data type: VISIBLE_STRING

Index: 9663 = 0x25BF

Input/output of the I&M2 date of installation

The Lenze setting shows an empty string.

Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT

Parameter | Name:

C14913 | I&M3 additional information

Data type: VISIBLE_STRING

Index: 9662 = 0x25BE

Input/output if the I&M3 additional information

The Lenze setting shows an empty string.

Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
